Delta AH Motion Series User Manual

AH Motion – Hardware Manual
3-76
_3
0.9
0.8
3.10
3.11
0.9
0.8
3.10
3.11
0.7 0.6 3.12 3.13 0.7 0.6 3.12 3.13
0.5
0.4
3.14
3.15
0.5
0.4
3.14
3.15
0.3
0.2
ZP
ZP
0.3
0.2
ZP
ZP
0.1 0.0 UP UP 0.1 0.0 UP UP
 DB37 connector and the external terminal module
1. External terminal module for AH32AM10N-5B: UB-10-ID32B(DVPAETB-ID32B)
Terminals:
Upper
row
X0 X2 X4 X6 X10 X12 X14 X16 X20 X22 X24 X26 X30 X32 X34 X36 S/S S/S
Lower
row
X1 X3 X5 X7 X11 X13 X15 X17 X21 X23 X25 X27 X31 X33 X35 X37 S/S S/S
AH series terminals:
Upper
row
X0.0 X0.2 X0.4 X0.6 X0.8
X
0.10 X0.12
X
0.14 X1.0 X1.2 X1.4 X1.6 X1.8 X1.10 X1.12
X
1.14 S/S S/S
Lower
row
X0.1 X0.3 X0.5 X0.7 X0.9
X
0.11 X0.13
X
0.15 X1.1 X1.3 X1.5 X1.7 X1.9 X1.11 X1.13
X
1.15 S/S S/S
2. External terminal modules for AH32AN02T-5B
 UB-10-OT32B(DVPAETB-OT32B)
Terminals:
Upper
row
Y0 Y2 Y4 Y6 Y10 Y12 Y14 Y16 Y20 Y22 Y24 Y26 Y30 Y32 Y34 Y36 UP UP
Lower
row
Y1 Y3 Y5 Y7 Y11 Y13 Y15 Y17 Y21 Y23 Y25 Y27 Y31 Y33 Y35 Y37 ZP ZP
AH series terminals:
Upper
Y0.0 Y0.2 Y0.4 Y0.6 Y0.8 Y0.10 Y0.12
Y
0.14 Y1.0 Y1.2 Y1.4 Y1.6 Y1.8 Y1.10 Y1.12 Y1.14 UP UP
