A.1 EMC Standards for an AH Motion System
A.1.1 EMC Standards Applicable to an AH Motion System
The EMC standards which are applicable to an AH Motion system are listed below.
 EMI
Port Frequency range Level (Normative) Reference standard
Enclosure port
(radiated)
(measured at a distance
of 10 meters)
30-230 MHz 40 dB (μV/m) quasi-peak
IEC 61000-6-4
230-1000 MHz 47 dB (μV/m) quasi-peak
AC power port
(conducted)
0.15-0.5 MHz
79 dB (μV) quasi-peak
IEC 61000-6-4
66 dB (μV) average
0.5-30 MHz
73 dB (μV) quasi-peak
60 dB (μV) average
 EMS
Environmental
phenomenon
Reference
standard
Test Test level
Electrostatic discharge
IEC 61000-4-2
Contact
± 4 kV
Air
± 8
kV
Radio frequency
electromagnetic field
Amplitude modulated
IEC 61000-4-3
80% AM,
1 kHz sinusoidal
2.0-2.7 GHz 1 V/m
1.4-2.0 GHz 3 V/m
80-1000 MHz 10 V/m
Power frequency magnetic
field
IEC 61000-4-8
60 Hz 30 A/m
50 Hz 30 A/m
