Delta AH Motion Series User Manual

Chapter 3 Product Specifications
3-17
3_
Number
Name
Description
8 Ethernet port Providing the Ethernet communication interface
9
Set screw
Fixing the module
10
Label
Nameplate
11 Hook Connecting the module and a backplane.
Dimensions:
Dimensions are in mm.
3.2.6 Arrangement of Terminals
 AHxxEMC-5A
Pin Terminal
Function
Pin Terminal
Function
Pulse
Count
Pulse
Count
1
COM
COM
19
Y0.11
Out3
2
COM
COM
20
Y0.10
Out2
3
COM
COM
21
Y0.9
Out1
4 COM COM 22 Y0.8 Out0
5
S/S
COM
23
X1.3
CntA5
6
X1.5
Rst5
24
X1.2
CntA5
7 S/S S/S 25 X1.1 CntA4
8
X1.4
Rst4
26
X1.0
CntA4
9
S/S
S/S
27
X0.15
DOG3
CntA3
10
X0.3
Rst3
28
X0.14
DOG2
CntA3
11 S/S S/S 29 X0.13
DOG1
CntB2
12
X0.2
Rst2
30
X0.12
DOG0
CntA2
13
X0.1-
Rst1-
31
X0.1+
Rst1+
14 X0.11-
DOG5-
CntB1- 32 X0.11+
DOG5+
CntB1+
RUN
ETH
ERROR
RUN
Ethernet
EtherCAT
CN1
RUN
STOP
Micro SD
EtherCAT
10EMC
ETH
ERROR
