Delta AH Motion Series User Manual

AH Motion – Hardware Manual
3-78
_3
AH series terminals:
Upper
row
Y0.0 Y0.2 Y0.4 Y0.6 Y0.8 Y0.10 Y0.12 Y0.14 Y1.0 Y1.2 Y1.4 Y1.6 Y1.8 Y1.10 Y1.12
Y
1.14 UP UP
Lower
row
Y0.1 Y0.3 Y0.5 Y0.7 Y0.9 Y0.11 Y0.13 Y0.15 Y1.1 Y1.3 Y1.5 Y1.7 Y1.9 Y1.11 Y1.13
Y
1.15 ZP ZP
 UB-10-OR32B(DVPAETB-OR32B)
Terminals:
GND +24V
1
st
from
the left
C0 Y0 Y1 Y2 Y3 C1 Y4 Y5 Y6 Y7 C2 Y10 Y11 Y12 Y13 C3 Y14 Y15 Y16 Y17
21
st
from
the left
C4 Y20 Y21 Y22 Y23 C5 Y24 Y25 Y26 Y27 C6 Y30 Y31 Y32 Y33 C7 Y34 Y35 Y36 Y37
AH series terminals:
GND
+24V
1
st
from
the left
C0 Y0.0 Y0.1 Y0.2 Y0.3 C1 Y0.4 Y0.5 Y0.6 Y0.7 C2 Y0.8 Y0.9 Y0.10 Y0.11 C3 Y0.12 Y0.13 Y0.14 Y0.15
21
st
from
the left
C4 Y1.0 Y1.1 Y1.2 Y1.3 C5 Y1.4 Y1.5 Y1.6 Y1.7 C6 Y1.8 Y1.9 Y1.10 Y1.11 C7 Y1.12 Y1.13 Y1.14 Y1.15
 MIL connector and the external terminal module
1. External terminal module for AH64AM10N-5C: UB-10-ID32A(DVPAETB-ID32A)
Terminals:
Upper row
S/S
S/S
X0
X2
X4
X6
X10
X12
X14
X16
X20
X22
X24
X26
X30
X32
X34
X36
Lower row
S/S S/S X1 X3 X5 X7 X11 X13 X15 X17 X21 X23 X25 X27 X31 X33 X35 X37
