Delta AH Motion Series User Manual

Chapter 3 Product Specifications
3-87
3_
 AH08AD-5A/AH08DA-5A
6
7
1
2
3
4
5
08DA
RUN
E RRO R
VO5
IO5
AG
VO6
AG
IO6
AG
AG
AG
AG
IO7
VO7
ZP
SG
AG
UP
SG
AG
IO3
VO3
VO4
IO4
IO0
VO0
IO1
VO1
VO2
IO2
Number
Name
Description
1 Model name
Model name of the module
2
RUN LED
indicator
Operating status of the module
ON: The module is running.
OFF: The module stops running.
ERROR LED
indicator
Error status of the module
ON: A serious error occurs in the module.
OFF: The module is normal.
Blink: A slight error occurs in the module.
3
Removable
terminal block
The inputs are connected to sensors.
The outputs are connected to loads which will be driven.
4
Arrangement of
the input/output
terminals
Arrangement of the terminals
5
Description of the
inputs/outputs
Simple specifications for the module
6
Clip
Removing the terminal block
7 Label Nameplate
8
Set screw
Fixing the module
9
Connector
Connecting the module and a backplane
10
Projection
Fixing the module
