AH Motion Hardware Manual
4-6
_4
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, 0/4~20 mA, or -20~+20 mA
AH08AD-5A
Eight-channel analog input module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, 0/4~20 mA, or -20~+20 mA
AH08AD-5B
Eight-channel analog input module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V
AH08AD-5C
Eight-channel analog input module
16-bit resolution
0/4~20 mA or -20~+20 mA
AH04DA-5A
Four-channel analog output module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, or 0/4~20 mA
AH08DA-5A
Eight-channel analog output module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, or 0/4~20 mA
AH08DA-5B
Eight-channel analog output module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, or 0/1~5 V
AH08DA-5C
Eight-channel analog output module
16-bit resolution
0/4~20 mA
AH06XA-5A
Four-channel analog input and two-channel analog output module
16-bit resolution
Analog input: -10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, 0/4~20 mA, or -20~+20 mA
Analog output: -10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, or 0/4~20 mA
- Temperature measurement modules:
AH04PT-5A
Four-channel four-wire/three-wire RTD
Sensor type: Pt100, Pt1000, Ni100, Ni1000, or 0~300 Ω input impedance
AH08PTG-5A
Eight-channel four-wire/three-wire/two-wire RTD
Sensor type: Pt100, Pt1000, Ni100, Ni1000, or 0~300 Ω input impedance
AH04TC-5A
Four-channel thermocouple
Sensor type: J, K, R, S, T, E, N, or -150~+150 mV
AH08TC-5A
Eight-channel thermocouple
Sensor type: J, K, R, S, T, E, N, or -150~+150 mV
- Network modules:
AH10SCM-5A
Serial communication module with two RS-485/RS-422 ports, and supports MODBUS and
UD Link protocols.
One part of communication is isolated from the other part of the communication, and one
part of power is isolated from the other part of the power.
AH10COPM-5A
CANopen communication module. It can function as a master or a slave.
- Dummy module:
AHASP01-5A
Dummy module used for an empty I/O slot
