AH Motion – Hardware Manual

4-12

Type 1

Type 2

 Removal

1. Pull the clip in the direction indicated by the arrow. For high-definition terminals(Type 2), a flat head screw driver is

required to loose the screws on both ends.

Type 1

Type 2

Default Chapter2
