Chapter 4 Installation and Wiring
4-23
4_
Products
Model name
Internal power consumption
External power consumption
Motion control module
AH02HC-5A 2.4 W -
AH04HC-5A
2.4 W
-
AH05PM-5A
2.7 W
-
AH10PM-5A 2.7 W -
AH15PM-5A
2.7 W
-
AH20MC-5A
3 W
-
Digital I/O module
AH16AM10N-5A 0.1 W 1.9 W
AH16AM30N-5A
0.1 W
-
AH16AN01P-5A
0.2 W
0.4 W
AH16AN01R-5A
2.1 W
-
AH16AN01S-5A
0.6 W
-
AH16AN01T-5A
0.2 W
0.4 W
AH16AP11P-5A
0.2 W
0.2 W
AH16AP11R-5A 1.1 W -
AH16AP11T-5A
0.2 W
0.2 W
AH32AM10N-5A
0.2 W
3.8 W
AH32AM10N-5B 0.2 W 3.8 W
AH32AM10N-5C
0.2 W
3.8 W
AH32AN02P-5A
0.4 W
0.8 W
AH32AN02P-5B
0.4 W
0.8 W
AH32AN02P-5C
0.4 W
0.8 W
AH32AN02T-5A
0.4 W
0.8 W
AH32AN02T-5B
0.4 W
0.8 W
AH32AN02T-5C 0.4 W 0.8 W
AH64AM10N-5C
0.2 W
4.9 W
AH64AN02P-5C
0.6 W
1.5 W
AH64AN02T-5C 0.6 W 1.5 W
Analog I/O module
AH04AD-5A
0.35 W
1 W
AH04DA-5A
0.34 W
2.6 W
AH06XA-5A
0.34 W
1.4 W
AH08AD-5A 1.1W -
AH08DA-5A
0.36W
4.55W
AH08AD-5B
1.9 W
-
AH08DA-5B 0.25 W 2.2 W
AH08AD-5C
1.6 W
-
AH08DA-5C
0.25 W
3.7 W
Temperature
AH04PT-5A
2 W
-
