AH Motion – Hardware Manual
1-10
_1
General Specifications
AHxxEMC-5A Remark
Number of input/output
devices
X/Y devices (bit): 8192
(X0.0~X511.15/Y0.0~Y511.15)
X/Y devices (word): 512
(X0~X511/Y0~Y511)
Number of devices which can be
used in a program
Number of inputs/outputs
338 inputs/ 324 outputs (AHBP05M2-5A)
Number of inputs/outputs
accessible to an CPU
Input relay [X]
8192 (X0.0~X511.15)
Output relay [Y]
8192 (Y0.0~Y511.15)
Auxiliary relay [M]
8192 (M0~M8191)
Timer [T]
2048 (T0~T2047)
Counter [C]
2048 (C0~C2047)
32-bit counter [HC/AC]
HC: 64 (HC0~HC63)
AC: 56 (AC0~ AC55)
Data register [D]
D device (bit): 1048576 (D0.0~D65535.15)
D device (word): 65536 (D0~D65535)
Stepping relay [S]
2048 (bit) (S0~S2047)
Index register [E]
32 (word) (E0~E31)
Special auxiliary relay [SM
/AM/AR]
SM(bit): 2048 (SM0~SM2047)
AM(bit): 16384 (AM0~AM16383)
AR(bit):1048576 (AR0.15~AR65535.15)
Special data register [SR/AR]
SR(word): 2048 (SR0~SR2047)
AR(word): 65536 (AR0~AR65535)
Serial communication port
One RS-232(USB), One RS-485
communication port
Ethernet port
10/100 M
USB port
Mini USB
Memory card slot
Supports Micro SD card (SD 2.0)
Real-time clock
Years, months, days, hours, minutes,
seconds, and weeks
The function is available when the
CPU is used together with the
motion backplane
