Delta AH Motion Series User Manual

Chapter 3 Product Specifications
3-23
3_
 AHPS15-5A
1
2
PS15
NC
FG
24G
INPUT
VS
VS
FE
+24V
24VDC
POWER
PS15
POWER
3
4
5
Number
Name
Description
1 Model name Model name of the power supply module
2
POWER LED
indicator (green)
Indicating the status of the power supply
3
Arrangement of the
terminals
VS-: It is connected to the negative 24 VDC power supply.
VS+: It is connected to the positive 24 VDC power supply.
NC: No connection
FG: Functional ground
FE: Line ground
24G/+24V: DC power input
4
Terminal
Terminal for wiring
5
Label
Nameplate
Dimensions:
50
110
PS15
NC
FG
24G
INPUT
VS
VS
FE
+24V
24VDC
POWER
PS15
POWER
103
6
Dimensions are in mm.
