Delta AH Motion Series User Manual

Chapter 3 Product Specifications
3-53
3_
 Digital input specifications: 120 ~ 240 VAC
Model
Specifications
AH16AM30N-5A
Number of inputs
16
Connector type
Removable terminal block
Input type
Digital input
Input form
Alternating current
Input current
120 VAC and 4.5 mA; 240 VAC and 9 mA
Action
level
OFFON
>79 VAC
ONOFF
<40 VAC
Response
time
OFF

ON
15 ms
ONOFF
30 ms
Electrical isolation
Optocoupler
Input display
When the optocoupler is driven, the input LED indicator is ON.
 Digital output specifications
Model
Specifications
AH16AN
01R-5A
AH16AP
11R-5A
AH16AN
01T-5A
AH16AP
11T-5A
AH16AN
01P-5A
AH16AP
11P-5A
AH16AN
01S-5A
Number of outputs
16
8
16
8
16
8
16
Connector type
Removable terminal block
Output type
Realy-R
Transistor-T (sinking)
Transistor-P (sourcing)
TRIAC-S
Voltage specifications
250 VAC, and below 30
VDC
12~30 VDC
*2
12~30 VDC
*2
120/240
VAC
Max. load
Resistance
2 A/output
(5 A/COM)
0.5 A/output
(4 A/COM)
0.5 A/output
(4 A/COM)
0.5 A/output
(2 A/COM)
Inductance
Life cycle curve
*3
12 W (24 VDC) 12 W (24 VDC)
Not
applicable
Bulb
20 W (24 VDC)
100 W (230 VAC)
2 W (24 VDC) 2 W (24 VDC) 60 WAC
Max.
output
frequency
*1
Resistance
1 Hz 100 Hz 100 Hz 10 Hz
Inductance
0.5 Hz 0.5 Hz 0.5 Hz -
Bulb
1 Hz 10 Hz 10 Hz 10 Hz
Max.
Response
time
OFF

ON
10 ms 0.5 ms 0.5 ms
1 ms+0.5
AC cycles
ON

OFF
