Delta ASDA-A2 Series User Manual

Chapter 6 Control Mode of Operation ASDA-A2
6-6 Revision February, 2017
Pulse Specification Max. Input
Frequency
Voltage
Specification
Forward Current
High-speed
pulse
Differential
Signal
4 Mpps 5V < 25 mA
Low-speed pulse Differential
Signal
500 Kpps 2.8V ~ 3.7V < 25 mA
Open-collector 200 Kpps 24V (Max.) < 25 mA
 The Source of External Pulse:
0: Low-speed optical coupler (CN1 Pin: PULSE, SIGN)
1: High-speed differential (CN1 Pin: HPULSE, HSIGN)
Position pulse can be input from CN1 terminal, PULSE (43), /PULSE (41), HPULSE (38),
/HPULSE (29) and SIGN (36), /SIGN (37), HSIGN (46), /HSIGN (40). It could be open-collector
or Line Driver. Please refer to Chapter 3.9.1 for wiring method.

Delta ASDA-A2 Series Specifications

General

Enclosure Rating	IP20
Control Mode	Position, Speed, Torque
Communication Interface	RS-485, CANopen
Protection	Overcurrent, Overvoltage, Undervoltage, Overload, Overtemperature, Encoder error
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C to 65°C
Humidity	20% to 90% RH (non-condensing)
Altitude	1000m max
Cooling Method	Natural cooling or forced air cooling
Encoder Feedback	20-bit incremental encoder (standard), 17-bit absolute encoder (optional)
