Chapter 8 Parameters ASDA-A2
8-294 Revision February, 2017
Setting Value: 0x3A
DO Name Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_A Output the status of bit 10 of P4-06 Level
triggered
ALL
Setting Value: 0x3B
DO Name Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_B Output the status of bit 11 of P4-06 Level
triggered
ALL
Setting Value: 0x3C
DO Name Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_C Output the status of bit 12 of P4-06 Level
triggered
ALL
Setting Value: 0x3D
DO Name Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_D Output the status of bit 13 of P4-06 Level
triggered
ALL
Setting Value: 0x3E
DO Name Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_E Output the status of bit 14 of P4-06 Level
triggered
ALL
Setting Value: 0x3F
DO Name Function Description of Digital Output (DO)
Trigger
Method
Control
Mode
SDO_F Output the status of bit 15 of P4-06 Level
triggered
ALL
NOTE
1）When P2-18～P2-22 is set to 0, DO has no function.
