Parameters ASDA-B2-F
7-14 September, 2015
7
P0-21 CM5A Status Monitor Register 5 Selection
ddress: 002AH
002BH
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
-
Unit: - Range: 0 ~ 127
Format: DEC Data Size: 16-bit
Settings:
Please refer to the description of P0-02 for the setting value.
P0-22~P0-24
Reserved
P0-25 MAP1 Mapping Parameter# 1
ddress: 0032H
0033H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-35
Format: HEX Data Size: 32-bit
Settings:
Users can continuously read and write parameters that are not in the same group. The content of
the parameter that is specified by P0-35 will be shown in P0-25. Please refer to the description of
P0-35 for parameter setting.
P0-26 MAP2 Mapping Parameter# 2
ddress: 0034H
0035H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-36
Format: HEX Data Size: 32-bit
Settings:
The using method is the same as P0-25. The mapping target is set by parameter P0-36.
P0-27 MAP3 Mapping Parameter# 3
ddress: 0036H
0037H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-37
Format: HEX Data Size: 32-bit
Settings:
The using method is the same as P0-25. The mapping target is set by parameter P0-37.
P0-28 MAP4 Mapping Parameter# 4
ddress: 0038H
0039H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-38
Format: HEX Data Size: 32-bit
Settings:
The using method is the same as P0-25. The mapping target is set by parameter P0-38.
