Delta ASDA-B2-F Series User Manual

ASDA-B2-F Parameters
September, 2015 7-15
7
P0-29 MAP5 Mapping Parameter# 5
A
ddress: 003AH
003BH
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-39
Format: HEX Data Size: 32-bit
Settings:
The using method is the same as P0-25. The mapping target is set by parameter P0-39.
P0-30 MAP6 Mapping Parameter# 6
A
ddress: 003CH
003DH
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-40
Format: HEX Data Size: 32-bit
Settings:
The using method is the same as P0-25. The mapping target is set by parameter P0-40.
P0-31 MAP7 Mapping Parameter# 7
A
ddress: 003EH
003FH
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-41
Format: HEX Data Size: 32-bit
Settings:
The using method is the same as P0-25. The mapping target is set by parameter P0-41.
P0-32 MAP8 Mapping Parameter# 8
A
ddress: 0040H
0041H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: No need to initialize
Control
Mode:
ALL
Unit: - Range:
Determined by the corresponding
parameter of P0-42
Format: HEX Data Size: 32-bit
Settings:
The using method is the same as P0-25. The mapping target is set by parameter P0-42.
P0-33~P0-34 Reserved
P0-35 MAP1A Target Setting of Mapping Parameter P0-25
A
ddress: 0046H
0047H
Operational
Interface:
Panel / Software Communication
Related
Section:
4.3.5
Default: 0
Control
Mode:
ALL
Unit: - Range:
Determined by the communication
address of the parameter group
Format: HEX Data Size: 32-bit
Settings:
Select the data block to access the parameter corresponded by register 1. The mapping content is
32 bits wide and can map to two 16-bit parameters or one 32-bit parameter.
