Delta ASDA-B2-F Series User Manual

Appendix A Specifications ASDA-B2-F
A-24 September, 2015
A
Motor Frame Size: 100 ~ 130 mm
Note:
1. Dimensions are in millimeters.
2. Dimensions and weights of the servo drive may be changed without prior notice.
3. The boxes (□) in model stand for shaft end / brake or the number of oil seal.
4. The boxes (
ᇞ) in model stand for encoder type. Please refer to Chapter 1 for detailed description.
Model
E△1320□S F△1308□S F△1313□S G△1303□S G△1306□S G△1309□S
LC 130 130 130 130 130 130
LZ 9 9 9 9 9 9
LA 145 145 145 145 145 145
S
)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


LB
)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


LL
(without
brake)
187.5 152.5 187.5 147.5 147.5 163.5
LL
(with
brake)
216 181 216 183.5 183.5 198
LS 47 47 47 47 47 47
LR 55 55 55 55 55 55
LE 6 6 6 6 6 6
LG 11.5 11.5 11.5 11.5 11.5 11.5
LW 36 36 36 36 36 36
RH 18 18 18 18 18 18
WK 8 8 8 8 8 8
W 8 8 8 8 8 8
T 7 7 7 7 7 7
TP
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
