Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-3
Table 7-2
Table 7-3
Applicable
Motor
*
1
125% Braking Torque 10% ED *
2
Max. Braking Torque
HP kW
Braking
Torque
[kg-m]
Brake
Unit
*
3
Braking Resistor for each
Brake Unit
Resistor value
spec. for each
AC motor Drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
*
4
VFDB
300 220 148.9 4110*2 BR1K2W015*10
5 parallel,
2 series
24000W 3Ω 252 3.0 252 190.5
375 280 189.6 4160*2 BR1K5W012*12
6 parallel,
2 series
36000W 2Ω 380 2.0 380 288.8
425 315 213.3 4160*2 BR1K5W012*12
6 parallel,
2 series
36000W 2Ω 380 2.0 380 288.8
475 355 240.3 4185*2 BR1K5W012*14
7 parallel,
2 series
42000W 1.7Ω 450 1.7 450 344.2
600 450 304.7 4185*3 BR1K5W012*12
6 parallel,
2 series
54000W 1.3Ω 600 1.1 675 513.0
575V
Applicable
Motor (kW)
＊
1
125% Braking Torque / 10%ED ＊
2
Max. Braking Torque
LD ND HD
Braking
Torque
[kg-m]
Brake Unit
VFDB
＊
3
Braking
Resistor for each
Brake Unit
Resistor value spec.
for each AC motor
drive
Total
Braking
Current [A]
Min.
Resistor
Value [Ω]
Max. Total
Braking
Current [A]
Peak
Power
[kW]
1.5 0.75 0.75 0.5
-
BR080W750*1 80W 750Ω 1.2 280.0 4 4.5
2.2 1.5 1.5 1
-
BR200W360*1 200W 360Ω 2.6 186.7 6 6.7
3.7 2.2 2.2 1.5
-
BR300W400*1 300W 400Ω 2.3 160.0 7 7.8
5.5 3.7 3.7 2.5
-
BR500W100*1 500W 100Ω 9.2 93.3 12 13.4
7.5 5.5 3.7 3.7
-
BR750W140*1 750W 140Ω 6.6 80.0 14 15.7
11 7.5 7.5 5.1
-
BR1K0W075*1 1000W 75Ω 12.3 70.0 16 17.9
15 11 7.5 7.4
-
BR1K1W091*1 1100W 91Ω 10.1 62.2 18 20.2
690V
Applicable
Motor (kW)
＊
1
125% Braking Torque / 10%ED ＊
2
Max. Braking Torque
LD ND HD
Braking
Torque
[kg-m]
Brake
Unit
VFDB
＊
3
Braking Resistor series for
each Brake Unit
Resistor value
spec. for each
AC motor drive
Total
Braking
Current
[A]
Min.
Resistor
Value
[Ω]
Max.
Total
Braking
Current
[A]
Peak
Power
[kW]
18.5 15 11 10.2 - BR1K0W039*2 2 series 2000W 78Ω 14.4 58.9 19 21.3
22 18.5 15 12.5 - BR1K2W033*2 2 series 2400W 66Ω 17.0 58.9 19 21.3
30 22 18.5 14.9 - BR1K5W027*2 2 series 3000W 54Ω 20.7 43.1 26 29.1
37 30 22 20.3 - BR1K2W015*3 3 series 3600W 45Ω 24.9 43.1 26 29.1
45 37 30 25 6055*1 BR1K2W033*4
2 series,
2 parallel
4800W 33Ω 33.9 24.3 46 51.5
55 45 37 30.5 6055*1 BR1K5W027*4
2 series,
2 parallel
6000W 27Ω 41.5 24.3 46 51.5
75 55 45 37.2 6110*1 BR1K2W033*6
2 series,
3 parallel
7200W 22Ω 50.9 12.2 92 103.0
90 75 55 50.8 6110*1 BR1K5W027*6
2 series,
3 parallel
9000W 18Ω 62.2 12.2 92 103.0
110 90 75 60.9 6110*1 BR1K5W027*8
2 series,
4 parallel
12000W 13.5Ω 83.0 12.2 92 103.0
132 110 90 74.5 6160*1 BR1K2W015*12
3 series,
4 parallel
14400W 11.3Ω 99.6 8.2 136 152.3
160 132 110 89.4 6160*1 BR1K5W027*10
2 series,
5 parallel
15000W 10.8Ω 103.7 8.2 136 152.3
200 160 132 108.3 6200*1 BR1K5W027*12
2 series,
6 parallel
18000W 9.0Ω 124.4 6.9 162 181.4
250 200 160 135.4 6110*2 BR1K5W027*8
2 series,
4 parallel
24000W 6.8Ω 165.9 6.1 184 206.1
315 250 200 169.3 6160*2 BR1K5W027*10
2 series,
5 parallel
30000W 5.4Ω 207.4 4.1 272 304.6
400 315 250 213.3 6200*2 BR1K5W027*12
2 series,
6 parallel
36000W 4.5Ω 248.9 3.5 324 362.9
