Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-12
690V, 50/60 Hz, 3-phase
kW HP
Rated current Saturation Current 3% Impedance 5% Impedance
(Arms) (Arms) (mH) (mH)
Light
Duty
Normal
Duty
Heavy
Duty
Light
Duty
Normal
Duty
Heavy
Duty
Light
Duty
Normal
Duty
Heavy
Duty
Light
Duty
Normal
Duty
Heavy
Duty
VFD185C63B-21 25 24 20 14 28.8 30.0 25.2 1.585 1.902 2.717 2.642 3.170 4.529
VFD220C63B-21 30 30 24 20 36.0 36.0 36.0 1.268 1.585 1.902 2.113 2.642 3.170
VFD300C63B-21 40 36 30 24 43.2 45.0 43.2 1.057 1.268 1.585 1.761 2.113 2.642
VFD370C63B-21 50 45 36 30 54.0 54.0 54.0 0.845 1.057 1.268 1.409 1.761 2.113
VFD450C63B-00/21 60 54 45 36 64.8 67.5 64.8 0.704 0.845 1.057 1.174 1.409 1.761
VFD550C63B-00/21 75 67 54 45 80.4 81.0 81.0 0.568 0.704 0.845 0.946 1.174 1.409
VFD750C63B-00/21 100 86 67 54 103.2 100.5 97.2 0.442 0.568 0.704 0.737 0.946 1.174
VFD900C63B-00/21 125 104 86 67 124.8 129.0 120.6 0.366 0.442 0.568 0.610 0.737 0.946
VFD1100C63B-00/21 150 125 104 86 150.0 156.0 154.8 0.304 0.366 0.442 0.507 0.610 0.737
VFD1320C63B-00/21 175 150 125 104 180.0 187.5 187.2 0.254 0.304 0.366 0.423 0.507 0.610
VFD1600C63B-00/21 215 180 150 125 216.0 225.0 225.0 0.211 0.254 0.304 0.352 0.423 0.507
VFD2000C63B-00/21 270 220 180 150 264.0 270.0 270.0 0.173 0.211 0.254 0.288 0.352 0.423
VFD2500C63B-00/21 335 290 220 180 348.0 330.0 324.0 0.131 0.173 0.211 0.219 0.288 0.352
VFD3150C63B-00/21 425 350 290 220 420.0 435.0 396.0 0.109 0.131 0.173 0.181 0.219 0.288
VFD4000C63B-00/21 530 430 350 290 516.0 525.0 522.0 0.088 0.109 0.131 0.147 0.181 0.219
VFD4500C63B-00/21 600 465 385 310 558.0 577.5 558.0 0.082 0.099 0.123 0.136 0.165 0.205
VFD5600C63B-00/21 745 590 465 420 708.0 697.5 756.0 0.064 0.082 0.091 0.107 0.136 0.151
VFD6300C63B-00/21 850 675 675 675 810.0 1012.5 1215.0 0.056 0.056 0.056 0.094 0.094 0.094
Table 7-18

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
