Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-38
460V Model
Rated current
(ND) (Arms)
Without AC reactor With AC reactor
Shielded Cable
[meter]
Non-shielded
cable [meter]
Shielded Cable
[meter]
Non-shielded
cable [meter]
VFD007C43A 3 50 75 75 115
VFD015C43A 4 50 75 75 115
VFD022C43A 6 50 75 75 115
VFD037C43A 9 50 75 75 115
VFD040C43A 10.5 50 75 75 115
VFD055C43A 12 50 75 75 115
VFD075C43A 18 100 150 150 225
VFD110C43A 24 100 150 150 225
VFD150C43A 32 100 150 150 225
VFD185C43A 38 100 150 150 225
VFD220C43A 45 100 150 150 225
VFD300C43A 60 100 150 150 225
VFD370C43S/U 73 100 150 150 225
VFD450C43S/U 91 150 225 225 325
VFD550C43A/E 110 150 225 225 325
VFD750C43A/E 150 150 225 225 325
VFD900C43A/E 180 150 225 225 325
VFD1100C43A/E 220 150 225 225 325
VFD1320C43A/E 260 150 225 225 325
VFD1600C43A/E 310 150 225 225 325
VFD1850C43A/E 370 150 225 225 325
VFD2200C43A/E 460 150 225 225 325
VFD2800C43A 550 150 225 225 325
VFD3150C43A 616 150 225 225 325
VFD3550C43A 683 150 225 225 325
VFD4500C43A 866 150 225 225 325
460V
Rated current
(ND) (Arms)
Without AC reactor With AC reactor
EMC Filter built-in model
Shielded Cable
[meter]
Non-shielded
cable [meter]
Shielded Cable
[meter]
Non-shielded
cable [meter]
VFD007C43E 3 30 75 30 115
VFD015C43E 4 30 75 30 115
VFD022C43E 6 30 75 30 115
VFD037C43E 9 30 75 30 115
VFD040C43E 10.5 30 75 30 115
VFD055C43E 12 30 75 30 115
VFD075C43E 18 50 150 50 225
VFD110C43E 24 50 150 50 225
VFD150C43E 32 50 150 50 225
VFD185C43E 38 50 150 50 225
VFD220C43E 45 50 150 50 225
VFD300C43E 60 50 150 50 225
Table 7-46
Table 7-47

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
