Chapter 7 Optional AccessoriesC2000
7-39
575V
kW HP
Rated
Current
Without AC reactor With AC reactor
Model
Normal
Duty
(Arms)
Shielded
Cable
[meter]
Non-shielded
Cable [meter]
Shielded
Cable
[meter]
Non-shielded
Cable [meter]
VFD015C53A-21
0.75 1 2.5 35 30 45 20
VFD022C531-21
1.5 2 3.6 35 30 45 20
VFD037C53A-21
2.2 3 5.5 35 30 45 20
VFD055C53A-21
3.7 5 8.2 35 30 45 20
VFD075C53A-21
5.5 7.5 10 35 30 45 20
VFD110C53A-21
7.5 10 15.5 35 30 45 20
VFD150C53A-21
11 15 20 35 30 45 20
690V
kW HP
Rated
Current
Without AC reactor With AC reactor
Model
Normal
Duty
(Arms)
Shielded
Cable
[meter]
Non-shield
ed Cable
[meter]
Shielded
Cable
[meter]
Non-shield
ed Cable
[meter]
VFD185C63B-21
18.5 25
20 20 35 30 45
VFD220C63B-21
22 30
24 20 35 30 45
VFD300C63B-21
30 40
30 20 35 45 60
VFD370C63B-21
37 50
36 20 45 60 75
VFD450C63B-00/21
45 60
45 20 45 60 75
VFD550C63B-00/21
55 75
54 20 45 60 100
VFD750C63B-00/21
75 100
67 20 45 60 100
VFD900C63B-00/21
90 125
86 20 45 75 100
VFD1100C63B-00/21
110 150
104 20 45 75 100
VFD1320C63B-00/21
132 175
125 20 45 75 100
VFD1600C63B-00/21
160 215
150 20 45 90 100
VFD2000C63B-00/21
200 270
180 20 45 90 100
VFD2500C63B-00/21
250 335
220 20 45 90 100
VFD3150C63B-00/21
315 425
290 20 45 90 100
VFD4000C63B-00/21
400 530
350 20 45 90 100
VFD4500C63B-00/21
450 600
385 20 45 90 100
VFD5600C63B-00/21
560 745
465 20 45 75 90
VFD6300C63B-00/21
630 850
675 20 45 75 90
* The table above is the suggested cable length of EMC built-in models operating under surge
voltage influencing. To pass the noise emission and Electromagnetic interference certification, the
cable length should follow chapter 7-7 instruction.
* 690V output motor cable length needs to comply with IEC 60034-25
Requirements on insulation level of Curve B motor
Table 7-48
Table 7-49
