Delta C2000 Series User Manual

Chapter 7 Optional AccessoriesC2000
7-42
380V~460V/ 50~60Hz
kW HP Rated current (Arms) Suggested sine-wave filter part #
Output cable length [m]
(Shielded or non-shielded)
0.75 1 3
B84143V0004R227
1000
1.5 2 4
2.2 3 6 B84143V0006R227
3.7 5 9
B84143V0011R227
4 5 10.5
5.5 7.5 12 B84143V0016R227
7.5 10 18
B84143V0025R227
11 15 24
15 20 32 B84143V0033R227
18.5 25 38
B84143V0050R227
22 30 45
30 40 60 B84143V0066R227
37 50 73 B84143V0075R227
45 60 91 B84143V0095R227
55 75 110 B84143V0132R227
75 100 150 B84143V0180R227
90 125 180 B84143V0180R227
1000
110 150 220 B84143V0250R227
132 175 260
B84143V0320R227
160 215 310
185 250 370
Please contact supplier EPCOS
220 300 460
280 375 550
315 420 616
355 475 683
450 600 866
Sine wave filter part #
Please refer to website:
http://en.tdk.eu/inf/30/db/emc_2014/B84143V_R227.pdf
B84143V0004R227 I
R
:4A, Sine-wave output filters for 3-phase systems
B84143V0006R227
I
R
:6A, Sine-wave output filters for 3-phase systems
B84143V0011R227
I
R
:11A, Sine-wave output filters for 3-phase systems
B84143V0016R227 I
R
:16A, Sine-wave output filters for 3-phase systems
B84143V0025R227
I
R
:25A, Sine-wave output filters for 3-phase systems
B84143V0033R227
I
R
:33A, Sine-wave output filters for 3-phase systems
B84143V0050R227 I
R
:50A, Sine-wave output filters for 3-phase systems
B84143V0066R227
I
R
:66A, Sine-wave output filters for 3-phase systems
Table 7-51

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
