Chapter 11 Summary of Parameter SettingsC2000
11-17
Pr. Parameter Name Setting Range Default
36: Error output selection 2 (Pr. 06-24)
37: Error output selection 3 (Pr. 06-25)
38: Error output selection 4 (Pr. 06-26)
39: Position reached (Pr. 10-19)
40: Speed reached (including stop)
41: Multi-position reached
42: Crane function
43: Actual motor speed higher than Pr. 02-47
44: Low current output (use with Pr. 06-71~06-73)
45: UVW output electromagnetic valve switch
46: Master dEb output
47: Closed brake output
49: Homing action complete output
50: Output control for CANopen
51: Analog output control for RS485 interface
(InnerCOM / MODBUS)
52: Output control for communication cards
65: Output for both CAN & 485 control
66: SO output logic A
67: Analog input level reached
68: SO output logic B
70: FAN warning output
02-18 Multi-function output direction 0000h~FFFFh (0: N.O.; 1: N.C.) 0000h
02-19
Terminal counting value reached
(returns to 0)
0–65500 0
02-20
Preliminary counting value reached
(does not return to 0)
0–65500 0
02-21 Digital output gain (DFM) 1–166 1
02-22 Desired frequency reached 1 0.00–599.00Hz
60.00 /
50.00
02-23
The width of the desired frequency
reached 1
0.00–599.00Hz 2.00
02-24 Desired frequency reached 2 0.00–599.00Hz
60.00 /
50.00
02-25
The width of the desired frequency
reached 2
0.00–599.00Hz 2.00
02-32 Brake delay time 0.000–65.000 sec. 0.000
02-33
Output current level setting for
multi-function output terminal
0–100% 0
