Chapter 11 Summary of Parameter SettingsC2000
11-16
Pr. Parameter Name Setting Range Default
02-13 Multi-function output 1 RLY1 0: No function 11
02-14 Multi-function output 2 RLY2 1: Indication during RUN 1
02-16 Multi-function output 3 (MO1) 2: Operation speed reached 66
02-17 Multi-function output 4 (MO2) 3: Desired frequency reached 1 (Pr. 02-22) 0
02-36
Output terminal of the I/O extension
card (MO10)
or (RA10)
4: Desired frequency reached 2 (Pr. 02-24)
5: Zero speed (Frequency command)
0
02-37
Output terminal of I/O extension card
(MO11)
or (RA11)
6: Zero speed including STOP (Frequency
command)
0
02-38
Output terminal of I/O extension card
(RA12)
7: Over-torque 1 (Pr. 06-06–06-08)
8: Over-torque 2 (Pr. 06-09–06-11)
0
02-39
Output terminal of I/O extension card
(RA13)
9: Drive is ready
10: Low voltage warning (Lv) (Pr. 06-00)
0
02-40
Output terminal of I/O extension card
(RA14)
11: Malfunction indication
12: Mechanical brake release (Pr. 02-32)
0
02-41
Output terminal of I/O extension card
(RA15)
13: Over-heat warning (Pr. 06-15)
14: Software brake signal indication (Pr. 07-00)
0
02-42
Output terminal of I/O extension card
(MO16 virtual terminal)
15: PID feedback error (Pr. 08-13, Pr. 08-14)
16: Slip error (oSL)
0
02-43
Output terminal of I/O extension card
(MO17 virtual terminal)
17: Count value reached, does not return to 0
(Pr. 02-20)
0
02-44
Output terminal of I/O extension card
(MO18 virtual terminal)
18: Count value reached, returns to 0
(Pr. 02-19)
0
02-45
Output terminal of I/O extension card
(MO19 virtual terminal)
19: External interrupt B.B. input (Base Block)
20: Warning output
0
02-46
Output terminal of I/O extension card
(MO20 virtual terminal)
21: Over-voltage
22: Over-current stall prevention
0
23: Over-voltage stall prevention
24: Operation mode
25: Forward command
26: Reverse command
27: Output when current ≥ Pr. 02-33
28: Output when current < Pr. 02-33
29: Output when frequency ≥ Pr. 02-34
30: Output when frequency < Pr. 02-34
31: Y-connection for the motor coil
32:
ᇞ-connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed including stop (actual output
frequency)
35: Error output selection 1 (Pr. 06-23)
