Delta C2000 Series User Manual

Chapter 2 InstallationC2000
2-5
2-2 Air Flow and Power Dissipation
Air flow rate for cooling
Power dissipation of AC motor drive
Model No.
Flow Rate [cfm] Flow Rate [m
3
/hr] Power Dissipation [W]
External Internal Total External Internal Total
Loss External
(Heat sink)
Internal Total
VFD007C23A - - - - - - 33 27 61
VFD015C23A 14 - 14 24 - 24 56 31 88
VFD022C23A 14 - 14 24 - 24 79 36 115
VFD037C23A 10 - 10 17 - 17 113 46 159
VFD055C23A 40 14 54 68 24 92 197 67 264
VFD075C23A 66 14 80 112 24 136 249 86 335
VFD110C23A 58 14 73 99 24 124 409 121 529
VFD150C23A 166 12 178 282 20 302 455 161 616
VFD185C23A 166 12 178 282 20 302 549 184 733
VFD220C23A 166 12 178 282 20 302 649 216 865
VFD300C23A/E 179 30 209 304 51 355 913 186 1099
VFD370C23A/E 179 30 209 304 51 355 1091 220 1311
VFD450C23A/E 228 73 301 387 124 511 1251 267 1518
VFD550C23A/E 228 73 301 387 124 511 1401 308 1709
VFD750C23A/E 246 73 319 418 124 542 1770 369 2139
VFD900C23A/E 224 112 336 381 190 571 2304 484 2788
VFD007C43A/E - - - - - - 33 25 59
VFD015C43A/E - - - - - - 45 29 74
VFD022C43A/E 14 - 14 24 - 24 71 33 104
VFD037C43A/E 10 - 10 17 - 17 103 38 141
VFD040C43A/E 10 - 10 17 - 17 116 42 158
VFD055C43A/E 10 - 10 17 - 17 134 46 180
VFD075C43A/E 40 14 54 68 24 92 216 76 292
VFD110C43A/E 66 14 80 112 24 136 287 93 380
VFD150C43A/E 58 14 73 99 24 124 396 122 518
VFD185C43A/E 99 21 120 168 36 204 369 138 507
VFD220C43A/E 99 21 120 168 36 204 476 158 635
VFD300C43A/E 126 21 147 214 36 250 655 211 866
VFD370C43S/U 179 30 209 304 51 355 809 184 993
VFD450C43S/U 179 30 209 304 51 355 929 218 1147
VFD550C43A/E 179 30 209 304 51 355 1156 257 1413
VFD750C43A/E 186 30 216 316 51 367 1408 334 1742
VFD900C43A/E 257 73 330 437 124 561 1693 399 2092
VFD1100C43A/E 223 73 296 379 124 503 2107 491 2599
VFD1320C43A/E 224 112 336 381 190 571 2502 579 3081
VFD1600C43A/E 289 112 401 491 190 681 3096 687 3783
VFD1850C43A/E 454 771 4589
VFD2200C43A/E 454 771 5772
VFD2800C43A/E 769 1307 6381
VFD3150C43A/E 769 1307 7156
VFD3550C43A/E 769 1307 8007
VFD4500C43A/E 769 1307 11894
VFD015C53A-21 - - - - - - 39.5 13.0 53
VFD022C53A-21 - - - - - - 55.0 22.0 77
VFD037C53A-21 0.006 - 0.006 13.6 - 13.6 86.8 42.7 130
VFD055C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 124.6 67.9 193
VFD075C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 143.5 119.0 263
VFD110C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 222.2 162.8 385
VFD150C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 308.5 216.5 525
VFD185C63B-21 90.0 21.3 111.4 153.0 36.2 189.2 317.5 145.0 462.5
VFD220C63B-21 90.0 21.3 111.4 153.0 36.2 189.2 408.2 141.8 550.0
VFD300C63B-21 90.0 21.3 111.4 153.0 36.2 189.2 492.7 257.3 750.0

Delta C2000 Series Specifications

General

Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Overload Capacity	150% of rated current for 60 seconds
Communication	DeviceNet
Protection	Overvoltage, Undervoltage, Overcurrent, Overload, Overheat
Humidity	5% to 95% (non-condensing)
Cooling	Forced air cooling
Control Mode	V/F Control, Sensorless Vector Control
