Chapter 12 Description of Parameter SettingsC2000
12.1-06-9
Stall Prevention Limit Level (Weak Magnetic Area Current Stall Prevention Level)
Default: 100
Settings 0–100% (Refer to Pr. 06-03, Pr. 06-04)
Sets the over-current stall prevention level when operation frequency is larger than Pr.01-01. This
parameter only works during acceleration.
Example: Pr. 06-03 = 150%, Pr. 06-04 = 100% and Pr. 06-16 = 80%, when the operation
frequency is larger than Pr. 01-01, the over-current stall prevention Level during acceleration is:
Pr. 06-03 × Pr. 06-16 = 150 × 80% = 120%.
Pr. 06-16 is invalid when the over-current stall prevention activates according to Pr. 06-04 at
constant speed.
Fault Record 1
Fault Record 2
Fault Record 3
Fault Record 4
Fault Record 5
Fault Record 6
Settings
0: No fault record
1: Over-current during acceleration (ocA)
2: Over-current during deceleration (ocd)
3: Over-current during constant speed(ocn)
4: Ground fault (GFF)
5: IGBT short-circuit (occ)
6: Over-current at stop (ocS)
7: Over-voltage during acceleration (ovA)
8: Over-voltage during deceleration (ovd)
9: Over-voltage during constant speed (ovn)
10: Over-voltage at stop (ovS)
11: Low-voltage during acceleration (LvA)
12: Low-voltage during deceleration (Lvd)
13: Low-voltage during constant speed (Lvn)
14: Low-voltage at stop (LvS)
15: Phase loss protection (OrP)
16: IGBT over-heat (oH1)
17: Capacitance over-heat (oH2)
18: tH1o (TH1 open: IGBT over-heat protection error)
19: tH2o (TH2 open: capacitance over-heat protection error)
21: Drive over-load (oL)
22: Electronics thermal relay protection 1 (EoL1)
23: Electronics thermal relay protection 2 (EoL2)
24: Motor PTC overheat (oH3) (PTC / PT100)
