Appendix B MODBUS TCP Map
B-3
_B
Address Offset
Data Type
Description
0x0030 20 words
Ex: Product Name = "DVW-W02W2-E2"
Word 0 Hi byte = 'D'
Word 0 Lo byte = 'V'
Word 1 Hi byte = W'
Word 1 Lo byte = '-'
Word 2 Hi byte = 'W'
Word 2 Lo byte = '0'
Word 3 Hi byte = '2'
Word 3 Lo byte = 'W'
Word 4 Hi byte = '2'
Word 4 Lo byte = '-'
Word 5 Hi byte = 'E'
Word 5 Lo byte = '2'
Word 6 Hi byte = '\0'
Word 6 Lo byte = '\0'
0x0050
20 words
Serial Number
0x0070 3 words
Ethernet MAC Address
Ex: MAC = 00:11:22:33:44:55
Word 0 Hi byte = 0x00
Word 0 Lo byte = '0x11
Word 1 Hi byte = 0x22
Word 1 Lo byte = 0x33
Word 2 Hi byte = 0x44
Word 2 Lo byte = '0x55
0x0073 2 words
Ethernet IP Address
Ex: IP = 192.168.1.5
Word 0 = 0xC0A8
Word 1 = 0x0105
0x0075 2 words
Ethernet Netmask
Ex: Mask = 255.255.255.0
Word 0 = 0xFFFF
Word 1 = 0xFF00
0x0077 2 words
Ethernet Gateway IP Address
Ex: IP = 192.168.1.1
Word 0 = 0xC0A8
Word 1 = 0x0101
0x0080 1 word
Power 1 Status
0x0000: OFF
0x0001: ON
0x0081 1 word
Power 2 Status
0x0000: OFF
0x0001: ON
0x0090 1 word
DO 1 Status
0x0000: OFF
0x0001: ON
0x00A0 1 word
DI 1 Status
0x0000: OFF
0x0001: ON
