DVW Series Industrial IEEE 802.11 a/b/g/n Wireless AP/WDS/Client/Gateway User Manual
3-30
3.3.1.7 Pair Connection Mode
Pair Connection Master and Slave modes connect two DVW series over a network. The serial device can
connect to a DVW series, and two DVW can use wired Ethernet cable or wireless way to connect each other.
Then two serial devices can overcome the distance limitation of serial interface.
Pair Connection Master Mode
Description Factory Default
Operation Mode
Display the operation mode of serial port. Pair Connection -
Master
Alive Check Time
Specify how long the DVW series sends a packet for checking the connection
still alive.
30
Destination IP
Specify the IP address for the destination DVW series with Pair Connection
Slave mode.
None
Destination Port
Specify the port number for the destination DVW series with Pair Connection
Slave mode.
None
