Appendix B MODBUS TCP Map
B-5
_B
Address Offset
Data Type
Description
WLAN Port Information
0x4000 1 word
WLAN Operation mode
0x0000: AP mode
0x0001: Client mode
0x0002: WLAN bridge (point to point)
0x0003: Wireless distribution system (point to
multipoint)
0x0004: Repeater mode
0x4100 1 words
WLAN Transmission mode
0x0000: Auto
0x0001: 802.11a
0x0002: 802.11b
0x0003: 802.11g
0x0004: 802.11n
Alarm
0x5000 1 word
Cold start alarm
0x0000: OFF
0x0001: ON
0xFFFF: Disable
0x5001 1 word
Warm start alarm
0x0000: OFF
0x0001: ON
0x5003 1 word
LAN link up alarm
0x0000: OFF
0x0001: ON
0x5004 1 word
Power state on alarm
0x0000: OFF
0x0001: ON
0x5005 1 word
Power state off alarm
0x0000: OFF
0x0001: ON
0x5006 1 word
DI on alarm
0x0000: OFF
0x0001: ON
0x5007 1 word
DI off alarm
0x0000: OFF
0x0001: ON
0x5008 1 word
authentication failure alarm
0x0000: OFF
0x0001: ON
0x5009 1 word
dot1d Bridge New Root alarm
0x0000: OFF
0x0001: ON
0x500A 1 word
dot1d Bridge Topology Changed alarm
0x0000: OFF
0x0001: ON
0x500C 1 word
Configuration Changed alarm
0x0000: OFF
0x0001: ON
0x500D 1 word
Firmware update alarm
0x0000: OFF
0x0001: ON
