Control Mode
Parameters Functions Settings
Factory
Setting
VF VG SV SG T TG
a
00-04
Definitions of the
Multi-Function
Display
20: the d axis voltage (Vector only)
21: Magnetic flux
22: Overload accumulated time
23: Electronic thermal relay
accumulated time
24: Execution time of the
multi-step speed
25: quiescence stage
26: over-torque accumulated time
27: DC braking time
28: compensated voltage
29: Slip compensation frequency
30: Running number of Encoder
(Channel 1)
31: PG position (position control)
32: Remaining pulses to reach
position control (home
position)
33: DC voltage upon a fault
34: The output AC voltage upon a
fault
35: The output frequency upon a
fault
36: The current value upon a fault
37: the frequency command upon
a fault
38: day (power-up time)
39: hour, minute
40: The upper bound frequency
value
41: Over-torque level
42: Stall level limitation
43: Torque compensation gain
44: torque limit (Pr. 06-12)
45: the q axis current (V/F and
vector)
46: Frequency of Encoder
(Channel 1)
49: PID error value
51: AVI input voltage
52: ACI input current
53: AUI input voltage
55: Auxiliary frequency value
60: Input state of digital terminals
61: Output state of digital terminals
84: Input frequency of pulse
(Channel 2)
