Delta VFD-V Series User Manual

5
VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
5-23
Settings Functions Explanations
40 P2P Hold
P2P is pause. AC drive keeps outputting at this
moment. It will keep on unfinished jog after
terminal is closed.
41 FWD Home Search
In speed mode, it will do FWD home search
according to the setting of 10-09.
42 P2P FWD Limit
In P2P mode, it is used with FWD limit sensor.
When it reaches FWD limit during running, it will
stop free running.
43 P2P REV Limit
In P2P mode, it is used with REV limit sensor.
When it reaches REV limit during running, it will
stop free running.
44 REV Home Search
In speed mode, it will do REV home search
according to the setting of 10-09.
02-07 UP/DOWN Key Mode
a
Factory setting 00000
Settings Bit 0 0 UP/DOWM following the acceleration/deceleration time
1
UP following the constant speed, and DOWN following the
deceleration time
Bit 1 0
UP following the acceleration time, and DOWN following the
constant speed
1 UP/DOWN following the constant speed
 The maximum Up/Down acceleration/deceleration speed is 10.00Hz/Sec.
02-08 The Acceleration/Deceleration Speed of the
UP/DOWN Key with Constant Speed
a
Factory setting 0.01
Settings 0.01~1.00Hz/msec
02-09 Digital Input Responding Time
a
Factory setting 0.005
Settings 0.001~30.000 Sec
 Function of this parameter is to delay or confirm the message of the digital input terminals;
the delayed time is the confirmation time, which will be helpful in preventing some
uncertain interferences that would consequently result in erroneous motions (except for
the counter input) in the input of the digital terminals (FWD, REV, and MI1~6), and under
this condition, confirmation for this parameter could be improved effectively, but the
responding time will be somewhat delayed.
