Group 4: Multi-Step Speed and Process Control Operation (PCO) Parameter
Control Mode
Parameters Functions Settings
Factory
Setting
VF VG SV SG T TG
a
04-00 The 1
st
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-01 The 2
nd
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-02 The 3
rd
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-03 The 4
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-04 The 5
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-05 The 6
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-06 The 7
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-07 The 8
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-08 The 9
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-09 The 10
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-10 The 11
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-11 The 12
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-12 The 13
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-13 The 14
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-14 The 15
th
Step Speed 0.00~400.00Hz 0.00
{ { { { ° °
a
04-15
Time Duration of the
PCO Master Speed
0.0~65500 Sec 0.0
{ { { { ° °
a
04-16
Time Duration of PCO
Step 1
0.0~65500 Sec 0.0
{ { { { ° °
a
04-17
Time Duration of PCO
Step 2
0.0~65500 Sec 0.0
{ { { { ° °
a
04-18
Time Duration of PCO
Step 3
0.0~65500 Sec 0.0
{ { { { ° °
a
04-19
Time Duration of PCO
Step 4
0.0~65500 Sec 0.0
{ { { { ° °
a
04-20
Time Duration of PCO
Step 5
0.0~65500 Sec 0.0
{ { { { ° °
a
04-21
Time Duration of PCO
Step 6
0.0~65500 Sec 0.0
{ { { { ° °
a
04-22
Time Duration of PCO
Step 7
0.0~65500 Sec 0.0
{ { { { ° °
a
04-23
Time Duration of PCO
Step 8
0.0~65500 Sec 0.0
{ { { { ° °
a
04-24
Time Duration of PCO
Step 9
0.0~65500 Sec 0.0
{ { { { ° °
a
04-25
Time Duration of PCO
Step 10
0.0~65500 Sec 0.0
{ { { { ° °
a
04-26
Time Duration of PCO
Step 11
0.0~65500 Sec 0.0
{ { { { ° °
