Delta VFD-V Series User Manual

VFD-V Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
5-38
123456789101112131415 0
Weights
Bit
0=Forward
1=Reverse
Direction of Pr.04-001st speed for
Direction of Pr.04-012nd speed for
Direction of Pr.04-023rd speed for
Direction of Pr.04-034th speed for
Direction of Pr.04-045th speed for
Direction of Pr.04-056th speed for
Direction of Pr.04-067th speed for
Direction of Pr.04-078th speed for
Direction of Pr.04-089th speed for
Direction of Pr.04-0910th speed for
Direction of Pr.04-1011th speed for
Direction of Pr.04-1112th speed for
Direction of 1 Pr.04-123th speed for
Direction of Pr.04-1314th speed for
Direction of Pr.04-1415th speed for
Simple Example
100111000110010 0
Weights
Bit
0=Forward
1=Reverse
Direction of Pr.04-00, 1st speed = Forward
Direction of Pr.04-01,2nd speed=Reverse
Direction of ,Pr.04-02 3rd speed=Forward
Direction of ,Pr.04-03 4th speed=Forward
Direction of ,Pr.04-04 5th speed=Reverse
Direction of Pr.04-05,6th speed=Reverse
Direction of Pr.04-06,7th speed=Reverse
Direction of Pr.04-07,8th speed=Forward
Direction of Pr.04-08,9th speed=Forward
Direction of Pr.04-09,10th speed=Forward
Direction of Pr.04-10,11th speed=Reverse
Directio n of Pr.0 4-11, 12th spe ed= Revers e
Direction of 1Pr.04-12, 3th speed=Forward
Direction of Pr.04-13,14th speed=Forward
Direction of Pr.04-14,15th speed=Reverse
The setting value = bit14x2 +
14
bit13x2 +....+bit2x2 +bit1x2 +bit0x2
13 2 1 0
= 1x2 +
14
1x2 +1x2 +1x2 +1x2 +1x2 +1x2
11106541
=16384+2048+1024+64+32+16+2
=19570
Setting 04-32
=19570
NOTE:
2 =16384
14
2=8192
13
2 =4096
12
2=2048
11
2 =1024
10
2=512
9
2=256
8
2=128
7
2=64
6
2=32
5
2=16
4
2=8
3
2=4
2
2=2
1
2=1
0
