Setting items Setting contents
Speaker Configuration
(Continued)
Front Height : Set the presence and size of the front height speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the front height speakers are not connected.
When the “Amp Assign” setting (vpage 34) is other than “Front
Height”, you cannot make the “Front Height” setting.
•
•
•
Front Wide : Set the presence and size of the front wide speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the front wide speakers are not connected.
When the “Amp Assign” setting (vpage 34) is other than “Front
Wide, you cannot make the “Front Wide” setting.
•
•
•
Bass Setting
Settings for subwoofer and
LFE signal range playback.
Subwoofer Mode : Select low range signals to be reproduced by
subwoofer.
LFE : The low range signal of the channel set to “Small” speaker size is
added to the LFE signal output from the subwoofer.
LFE+Main : The low range signal of all channels is added to the LFE
signal output from the subwoofer.
This can be set when “Speaker Configuration” – “Subwoofer” (vpage
34) is set to “Yes”.
Play music or a movie source and select the mode offering the strongest
bass.
Select “LFE+Main” if you want the bass signals to always be produced
from the subwoofer.
•
•
•
•
•
LPF for LFE : Set LFE signal playback range.
80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz / 250Hz•
Distance
Set distance from listening
position to speakers.
Measure beforehand the
distance from the listening
position to each speaker.
Feet / Meters : Set the unit of distance.
Step : Set the minimum variable width of the distance.
1ft / 0.1ft
0.1m / 0.01m
•
•
Default : Reset all distance settings to factory default.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
When you select “Default” and press ENTER, the “Return all settings
to the default?” prompt is displayed. Select either “Yes” or “No”,
and press ENTER.
•
•
Making Detailed Settings (Manual Setup)
See overleaf
Setting items Setting contents
Speaker Configuration
(Continued)
Surround A : Set the presence and size of the surround speakers A.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the surround speakers A are not connected.
When “Surround A” is set to “Large”, “Front Height” and “Front Wide“
can be set to “Large”.
When “Surround A” is set to “None”, “Surround B”, “Surround Back”,
“Front Height” and “Front Wide” can automatically set to “None”.
•
•
•
•
•
Surround B : Set the presence and size of the surround speakers B.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the surround speakers B are not connected.
When “Surround B” is set to “Large”, “Front Height” and “Front Wide“
can be set to “Large”.
When “Surround B” is set to “None”, “Surround A”, “Surround Back”,
“Front Height” and “Front Wide” can automatically set to “None”.
•
•
•
•
•
Surround Back : Set the presence, size and number of surround back
speakers.
Large : Use of a large speaker that can adequately playback low
frequencies.
Small : Use of a small speaker that has inadequate playback capacity for
low frequencies.
None : Select when the surround back speakers are not connected.
2spkrs : Use two surround back speakers.
1spkr : Use only one surround back speaker. When you select this
setting, connect the surround back speaker to the left (L) channel.
When the “Amp Assign” setting (vpage 34) is other than “Normal”,
you cannot make the “Surround Back” setting.
Even when the Surround Back Speaker setting is other than “None”,
sound may not be emitted from the surround back speaker, depending
on the playback source. In this case, “Surround Parameters” – “Surround
Back” setting other than “OFF” (vpage 74).
•
•
•
•
•
•
•
Main remote control
operation buttons
:Displaying the menu
Cancel the menu
:Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
Setting
