Getting Started Connections Playback Remote ControlMulti-zone Information Troubleshooting Specifications
Setting items Setting contents
Crossover Frequency
Outputs at below set
frequency, each speaker’s
bass signal output from
the subwoofer. Set this
according to the low
frequency reproduction
capabilities of the speakers
you are using.
40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /
250Hz : Set the crossover frequency.
Advanced : Specify crossover frequency for each speaker.
Front / Center / Surround A / Surround B / Surround A+B / Surround
Back / Front Height / Front Wide : Select the speaker.
40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz /150Hz / 200Hz /
250Hz : Set the crossover frequency.
Can be set when the “Speaker Configuration” – “Subwoofer” (vpage
34) setting is “Yes”, or when you have a speaker that is set to “Small”.
Always set the crossover frequency to “80Hz”. When using small
speakers, however, we recommend setting the crossover frequency to
a higher frequency.
For speakers set to “Small”, sound below the crossover frequency is cut
from the sound output. The cut bass sound is output from the subwoofer
or front speakers.
The speakers that can be set when “Advanced” is selected differ
according to the “Subwoofer Mode” setting (vpage 35).
When “LFE” is selected, speakers set to “Small” at “Speaker
Configuration” can be set. If the speakers are set to “Large”, “Full
Band” is displayed and the setting cannot be made.
If set to “LFE+Main”, this setting can be made regardless of the
speaker size.
•
•
•
•
•
•
•
•
Surround Speaker
Set the surround speakers
to use for every surround
mode.
DOLBY/DTS Cinema : Set the surround speakers to use during Dolby/
DTS Cinema mode.
DOLBY/DTS Music : Set the surround speakers to use during Dolby/DTS
Music mode.
DOLBY Game : Set the surround speakers to use during Dolby Game
mode.
DOLBY Height : Set the surround speakers to use during Dolby Height
mode.
WIDE SCREEN : Set the surround speakers to use during WIDE SCREEN
mode.
7CH STEREO : Set the surround speakers to use during 7CH STEREO
mode.
DSP SIMULATION : Set the surround speakers to use during the DENON
original surround mode.
MULTI CH MODE : Set the surround speakers to use during PCM or DSD
multi-channel mode.
A : Use surround speakers A.
B : Use surround speakers B.
A+B : Use surround speakers A and B.
“Surround Speaker” is displayed when “Speaker Configuration”
– “Surround A” and “Surround B” setting (vpage 35) is set to
“Large” or “Small”.
•
•
•
Setting items Setting contents
Distance
(Continued)
Front L / Front R / Center / Subwoofer / Surround A L / Surround A R
/ Surround B L / Surround B R / Surr. Back L
z
/ Surr. Back R
z
/ Front
Height L / Front Height R / Front Wide L / Front Wide R : Select the
speaker.
z: When the “Speaker Configuration” – “Surround Back” setting
(vpage 35) is set to “1spkr”, “Surr. Back” is displayed.
0.0ft ~ 60.0ft / 0.00m ~ 18.00m : Set the distance.
Speakers set to “None” in “Speaker Configuration” (vpage 34) are
not displayed.
The speakers that can be selected differ depending on the “Amp Assign”
(vpage 34) and “Speaker Configuration” (vpage 34) settings.
Default settings :
Front / Center / Subwoofer / Front Height / Front Wide : 12.0 ft (3.60 m)
Surround A / Surround B / Surround Back : 10.0 ft (3.00 m)
Set the difference in the distance between the speakers to less than 20
feet (6.0 meters).
•
•
•
•
•
Channel Level
Set the volume of the test
tone to be the same when it
is output from each speaker.
Surround Speaker : Set the surround speakers to output the test tone.
A : Output test tone from surround speakers A.
B : Output test tone from surround speakers B.
A+B : Output test tone from surround speakers A and B.
Can be set when the “Speaker Configuration” – “Surround A” or
“Surround B” setting is “Large” or “Small” (vpage 35).
•
•
•
Test Tone : Output test tone.
Front L / Front Height L / Center / Front Height R / Front R / Front
Wide R / Surround R /Surr. Back R
z
/Surr. Back L
z
/ Surround L /
Front Wide L / Subwoofer : Select the speaker.
z
: When the “Speaker Configuration” – “Surround Back” setting
(vpage 35) is set to “1spkr”, “Surr. Back” is displayed.
–12dB ~ +12dB (0dB) : Adjust the volume.
Speakers set to “None” in the “Speaker Configuration” (vpage 34)
settings are not displayed.
When
o is pressed while the subwoofer volume is set to “–12 dB”, the
“Subwoofer” setting switches to “OFF”.
When using surround speakers, be sure to adjust the volume of the
different speakers.
When a headphones jack is inserted in the PHONES terminal of the AVR-
4310CI, the “Channel Level” is not displayed.
You can also press
CHANNEL LEVEL to set (vpage 81 “Adjust the
Volume of the Different Speakers“).
•
•
•
•
•
•
•
Default : Reset all channel level settings to factory default.
Yes : Reset to the defaults.
No : Do not reset to the defaults.
•
•
Making Detailed Settings (Manual Setup)
See overleaf
Main remote control
operation buttons
:Displaying the menu
Cancel the menu
:Moves the cursor
(Up/Down/Left/Right)
:Confirm the setting :Return to previous menu
Setting
