Denon AVR-4520 Service Manual

186
Ref. No. Part No. Part Name Remarks Q'ty New
36 41751001900AD DOOR SUB PANEL BK 1
36 41751001901AD DOOR SUB PANEL SP 1
37 457010003008M MAGNET DOOR SR7005 A332 1
38 44631006300AD EARTH PLATE DOOR 1
39 44631006700AD DOOR PLATE 1
40 00D4210763010 GEAR DAMPER 1
41 44531013600AD FRONT CHASSIS 1
42 44551013900AD FFC HOLDER (FLD) 1
43 44551013700AD FFC HOLDER (HDMI) 1
44 42451002900AD KNOB RING (M) BK 1
44 42451002901AD KNOB RING (M) SP 1
45 42451003000AD KNOB RING (F) BK 1
45 42451003001AD KNOB RING (F) SP 1
46 45151011700AD KNOB (M) SPACER KNOB (M) SPACER 1
47 45151011800AD KNOB (F) SPACER KNOB (F) SPACER 1
48 41201007500AD KNOB (M) ASSY BK 1
48 41201007501AD KNOB (M) ASSY SP 1
49 41201007600AD KNOB (F) ASSY BK 1
49 41201007601AD KNOB (F) ASSY SP 1
50 8S4031003800D TOP COVER SUB ASSY BK 1
50 8S4031003801D TOP COVER SUB ASSY SP 1
★
51 00D4458004007 WIRE CLAMPER 10
★
52 00D4458004007 WIRE CLAMPER 3
★
53 0RD4450048003 CORD HOLDER (L76) TRANS WIRE 1
★
54 00M32AK861900 CLEAR LABEL(44X12 T0.05) E3,E1C 1
★
55 L0020 MAC ADDRESS SUB ASSY 1
★
56 8W5441030800D LICENSE SUB ASSY E3 1
★
57 8W5441030801D LICENSE SUB ASSY E2,E1C 1
★
58 8W5441030802D LICENSE SUB ASSY JP 1
★
59 8W5451018300D CONT LABEL SUB ASSY E3 1
★
60 8W5451018301D CONT LABEL SUB ASSY BKE2 1
★
61 8W5451018302D CONT LABEL SUB ASSY SPE2 1
★
62 8W5451018303D CONT LABEL SUB ASSY E1C 1
★
63 8W5451018304D CONT LABEL SUB ASSY JP 1
★
64 54411031200AD POP LABEL (E3) E3 1
★
65 54411031300AD POP LABEL (E2) E2 1
★
66 54411031400AD POP LABEL (E1C) E1C 1
★
67 54411031500AD POP LABEL (JP) JP 1
★
68 52455000200AS SP RIVET E2,E1C 22
★
69 44801002700AS
GASKET NLCG-070100 W10xH7xD20x3pcs for
FRONT CHASSIS
1
★
70 44801002604AS
GASKET NLCG-040100 W10xH4xD20x2pcs for
REAR SIDE
1
★
71 44801002505AS
GASKET NLCG-015100 W10xH1.5xD20x2pcs for
REAR TOP
1
★
72 47101006600AS RUBBER SHEET (45X15.T6) E2,E1C,JP 4
★
73 47101006700AS RUBBER SHEET (15X15.T18) E2,E1C,JP 4
SCREWS
101 00M51270310U0 SCREW TRANS PLATE 10
101 00M51270310U0 SCREW JACK. BRACKET. AC INLET 31
101 00M51270310U0 SCREW SPEAKER 6
101 00M51270310U0 SCREW 1

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
