Denon AVR-4520 Service Manual

187
Ref. No. Part No. Part Name Remarks Q'ty New
101 00M51270310U0 SCREW CHASSIS + BACK PANEL 6
101 00M51270310U0 SCREW PWB ASSY + TRANS PLATE 2
101 00M51270310U0 SCREW AL PLATE + CHASSIS 2
101 00M51270310U0 SCREW SMPS COVER + CHASSIS 1
101 00M51270310U0 SCREW RADIATOR BRACKET L/R 4
101 00M51270310U0 SCREW PWB BRACKET (A.REG) 2
101 00M51270310U0 SCREW RADIATOR BRACKET L/R 4
101 00M51270310U0 SCREW F/PANEL + CHASSIS 8
101 00M51270310U0 SCREW 3
102 00M51280308U0 SCREW-B FOOT 4
102 00M51280308U0 SCREW-B 2
102 00M51280308U0 SCREW-B SMPS COVER 2
102 00M51280308U0 SCREW-B DSP STAY 2
102 00M51280308U0 SCREW-B PWB ASSY + CHASSIS 2
102 00M51280308U0 SCREW-B DOOR + DOOR SUB PANEL 2
102 00M51280308U0 SCREW-B DAMPER 2
102 00M51280308U0 SCREW-B FLD PWB 18
102 00M51280308U0 SCREW-B F/PANEL + CHASSIS (SIDE) 2
103 0RD4713302017 3X5 CBS NETWORK + M3 1
103 0RD4713302017 3X5 CBS DIGITAL + M3 1
103 0RD4713302017 3X5 CBS BRIDGE PWB 4
104 0RD4770312008 4X8 TP SCREW TRANS 4
105 0RD4737015005 3X6 CBTS(S)-B HD TUNER 2
105 0RD4737015005 3X6 CBTS(S)-B CONNECT + M3 2
105 0RD4737015005 3X6 CBTS(S)-B CONNECT + SMPS COVER 2
105 0RD4737015005 3X6 CBTS(S)-B DSP STAY + M3 2
105 0RD4737015005 3X6 CBTS(S)-B HDMI. M3 12
105 0RD4737015005 3X6 CBTS(S)-B RADIATOR SUB 8
105 0RD4737015005 3X6 CBTS(S)-B M3 6
106 00M51280310U0 B.H.TAPPED EJ330106 2
107 00D4790003038 PUSH RIVET SP SCREW COVER 1
108 0RD4770153021 3X16 CPTS(B) SW W 9
108 0RD4770153021 3X16 CPTS(B) SW W 11
109 00D4790003025 PUSH RIVET FFC HOLDER (HDMI) 3
110 0RD4738064000 4X8 CBTS(B)-B-3P 8

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
