Denon AVR-4520 Service Manual

234
ADV8003
Pin No. Mnemonic Type Description
Y3 DDR_DQS[2] DDR interface Data Strobe for DDR Data Byte[23:16].
Y4 GND GND Ground.
Y5 DDR_DQ[23] DDR interface Data Line. Interface to external RAM data lines.
Y6 DVDD_DDR Power DDR Interface Supply (1.8 V).
Y7 DDR_DQS[3] DDR interface Data Strobe for DDR Data Byte[31:24].
Y8 GND GND Ground.
Y9 DDR_A[11] DDR interface Address Line. Interface to external RAM address lines.
Y10 DVDD_DDR Power DDR Interface Supply (1.8 V).
Y11 DDR_A[4] DDR interface Address Line. Interface to external RAM address lines.
Y12 GND GND Ground.
Y13
DDR_CAS
DDR interface Column Address Strobe for DDR Memory.
Y14 DVDD_DDR Power DDR Interface Supply (1.8 V).
Y15
DDR_CK
DDR interface DDR Memory Clock. Interface to external DDR RAM clock lines.
Y16 GND GND Ground.
Y17 DDR_DQ[9] DDR Interface Data Line. Interface to external RAM data lines.
Y18 DVDD_DDR Power DDR Interface Supply (1.8 V).
Y19 DDR_DQ[14] DDR interface Data Line. Interface to external RAM data lines.
Y20 GND GND Ground.
Y21 DDR_DQ[6] DDR interface Data Line. Interface to external RAM data lines.
Y22 PVDD_DDR Power DDR Interface PLL Supply (1.8 V).
Y23 GND GND Ground.
AA1 DDR_DQ[18] DDR interface Data Line. Interface to external RAM data lines.
AA2 GND GND Ground.
AA3 GND GND Ground.
AA4
DDR_DQS[2]
DDR interface Data Strobe for DDR Data Byte[23:16].
AA5 DDR_DQ[26] DDR interface Data Line. Interface to external RAM data lines.
AA6 DVDD_DDR Power DDR Interface Supply (1.8 V).
AA7
DDR_DQS[3]
DDR interface Data Strobe for DDR Data Byte[31:24].
AA8 NC/GND No connect/GND
For new ADV8003 designs, do not connect to this pin. For designs that must
maintain consistency with the ADV8002, this pin can be grounded.
AA9 DDR_A[8] DDR interface Address Line. Interface to external RAM address lines.
AA10 DVDD_DDR Power DDR Interface Supply (1.8 V).
AA11 DDR_A[2] DDR interface Address Line. Interface to external RAM address lines.
AA12 GND GND Ground.
AA13
DDR_CS
DDR interface DDR Chip Select. Interface to external DDR RAM chip selects.
AA14 DVDD_DDR Power DDR Interface Supply (1.8 V).
AA15 DDR_CK DDR interface DDR Memory Clock. Interface to external DDR RAM clock lines.
AA16 GND GND Ground.
AA17 DDR_DQ[11] DDR interface Data Line. Interface to external RAM data lines.
AA18 DVDD_DDR Power DDR Interface Supply (1.8 V).
AA19 DDR_DM[1] DDR interface Data Mask for Data Lines[15:8].
AA20 DDR_DM[0] DDR interface Data Mask for Data Lines[7:0].
AA21 GND GND Ground.
AA22 GND GND Ground.
AA23 DDR_DQ[3] DDR interface Data Line. Interface to external RAM data lines.
AB1 DDR_DQ[21] DDR interface Data Line. Interface to external RAM data lines.
AB2 DDR_DQ[19] DDR interface Data Line. Interface to external RAM data lines.
AB3 DDR_DQ[17] DDR interface Data Line. Interface to external RAM data lines.
AB4 DDR_DM[2] DDR interface Data Mask for Data Lines[23:16].
AB5 DDR_DQ[30] DDR interface Data Line. Interface to external RAM data lines.
AB6 DDR_DM[3] DDR interface Data Mask for Data Lines[31:25].
AB7 DDR_DQ[31] DDR interface Data Line. Interface to external RAM data lines.

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
