Denon AVR-4520 Service Manual

249
Ref. No. Part No. Part Name Remarks Q'ty New
C0302 133050086527S CQ93M2A102JT(PEF)
C0303 133050086565S CQ93M2A222JT(PEF)
C0304 nsp CC73CH1H101JT +1608
C0305 13405012940AS CE04W1C101MT(KR3)
C0306 13405013340AS CE04W1E471MT(KR3)
C0307 nsp CC73CH1H101JT +1608
C0309 133050086503S CQ93M2A221JT(PEF)
C0310 13405013340AS CE04W1E471MT(KR3)
C0311 00MDK9610430Y C1608X7R1H104K
C0313 00MDK9610430Y C1608X7R1H104K
C0314,0315 13405018640AS CE04W2A010MT(KR3)
C0316 133050083504S CQ93M2A473JT(PEF)
C0321,0322 13405018640AS CE04W2A010MT(KR3)
C0401 00D2544583971 CE04W1H470MT(ROB)
C0402 133050086527S CQ93M2A102JT(PEF)
C0403 133050086565S CQ93M2A222JT(PEF)
C0404 nsp CC73CH1H101JT +1608
C0405 13405012940AS CE04W1C101MT(KR3)
C0406 13405013340AS CE04W1E471MT(KR3)
C0407 nsp CC73CH1H101JT +1608
C0409 133050086503S CQ93M2A221JT(PEF)
C0410 13405013340AS CE04W1E471MT(KR3)
C0411 00MDK9610430Y C1608X7R1H104K
C0413 00MDK9610430Y C1608X7R1H104K
C0414,0415 13405018640AS CE04W2A010MT(KR3)
C0416 133050083504S CQ93M2A473JT(PEF)
C0421,0422 13405018640AS CE04W2A010MT(KR3)
C0501 00D2544583971 CE04W1H470MT(ROB)
C0502 133050086527S CQ93M2A102JT(PEF)
C0503 133050086565S CQ93M2A222JT(PEF)
C0504 nsp CC73CH1H101JT +1608
C0505 13405012940AS CE04W1C101MT(KR3)
C0506 13405013340AS CE04W1E471MT(KR3)
C0507 nsp CC73CH1H101JT +1608
C0509 133050086503S CQ93M2A221JT(PEF)
C0510 13405013340AS CE04W1E471MT(KR3)
C0511 00MDK9610430Y C1608X7R1H104K
C0513 00MDK9610430Y C1608X7R1H104K
C0514,0515 13405018640AS CE04W2A010MT(KR3)
C0516 133050083504S CQ93M2A473JT(PEF)
C0521,0522 13405018640AS CE04W2A010MT(KR3)
C0601 00D2544583971 CE04W1H470MT(ROB)
C0602 133050086527S
CQ93M2A102JT(PEF)
C0603 133050086565S CQ93M2A222JT(PEF)
C0604 nsp CC73CH1H101JT +1608
C0605 13405012940AS CE04W1C101MT(KR3)
C0606 13405013340AS CE04W1E471MT(KR3)
C0607 nsp CC73CH1H101JT +1608
C0609 133050086503S CQ93M2A221JT(PEF)
C0610 13405013340AS CE04W1E471MT(KR3)
C0611 00MDK9610430Y C1608X7R1H104K
C0613 00MDK9610430Y C1608X7R1H104K
C0614,0615 13405018640AS CE04W2A010MT(KR3)
C0616 133050083504S CQ93M2A473JT(PEF)
C0617-0620 00D2570522906 CK73B0J475KT +1608
C0621,0622 13405018640AS CE04W2A010MT(KR3)
C0701 00D2544583971 CE04W1H470MT(ROB)
C0702 133050086527S CQ93M2A102JT(PEF)
C0703 133050086565S CQ93M2A222JT(PEF)
C0704 nsp CC73CH1H101JT +1608
C0705 13405012940AS CE04W1C101MT(KR3)
C0706 13405013340AS CE04W1E471MT(KR3)
C0707 nsp CC73CH1H101JT +1608
C0709 133050086503S CQ93M2A221JT(PEF)
C0710 13405013340AS CE04W1E471MT(KR3)
C0711 00MDK9610430Y C1608X7R1H104K

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
