Denon AVR-4520 Service Manual

250
Ref. No. Part No. Part Name Remarks Q'ty New
C0713 00MDK9610430Y C1608X7R1H104K
C0714,0715 13405018640AS CE04W2A010MT(KR3)
C0716 133050083504S CQ93M2A473JT(PEF)
C0721,0722 13405018640AS CE04W2A010MT(KR3)
C0801 00D2544583971 CE04W1H470MT(ROB)
C0802 133050086527S CQ93M2A102JT(PEF)
C0803 133050086565S CQ93M2A222JT(PEF)
C0804 nsp CC73CH1H101JT +1608
C0805 13405012940AS CE04W1C101MT(KR3)
C0806 13405013340AS CE04W1E471MT(KR3)
C0807 nsp CC73CH1H101JT +1608
C0809 133050086503S CQ93M2A221JT(PEF)
C0810 13405013340AS CE04W1E471MT(KR3)
C0811 00MDK9610430Y C1608X7R1H104K
C0813 00MDK9610430Y C1608X7R1H104K
C0814,0815 13405018640AS CE04W2A010MT(KR3)
C0816 133050083504S CQ93M2A473JT(PEF)
C0821,0822 13405018640AS CE04W2A010MT(KR3)
C0901 00D2544583971 CE04W1H470MT(ROB)
C0902 133050086527S CQ93M2A102JT(PEF)
C0903 133050086565S CQ93M2A222JT(PEF)
C0904 nsp CC73CH1H101JT +1608
C0905 13405012940AS CE04W1C101MT(KR3)
C0906 13405013340AS CE04W1E471MT(KR3)
C0907 nsp CC73CH1H101JT +1608
C0909 133050086503S CQ93M2A221JT(PEF)
C0910 13405013340AS CE04W1E471MT(KR3)
C0911 00MDK9610430Y C1608X7R1H104K
C0913 00MDK9610430Y C1608X7R1H104K
C0914,0915 13405018640AS CE04W2A010MT(KR3)
C0916 133050083504S CQ93M2A473JT(PEF)
C0921,0922 13405018640AS CE04W2A010MT(KR3)
OTHERS PARTS GROUP
B9001,9002 00D2051034010 M3 SCREW TERMINAL
L0101 00D2350191007 INDUCTOR(1MH)
L0201 00D2350191007 INDUCTOR(1MH)
L0301 00D2350191007 INDUCTOR(1MH)
L0401 00D2350191007 INDUCTOR(1MH)
L0501 00D2350191007 INDUCTOR(1MH)
L0601 00D2350191007 INDUCTOR(1MH)
L0701 00D2350191007 INDUCTOR(1MH)
L0801 00D2350191007 INDUCTOR(1MH)
L0901 00D2350191007 INDUCTOR(1MH)
N0102
00MYP06003950 S5B-EH
N0202 00MYP06003950 S5B-EH
N0302 00MYP06003950 S5B-EH
N0402 00MYP06003950 S5B-EH
N0502 00MYP06003950 S5B-EH
N0602 00MYP06003950 S5B-EH
N0702 00MYP06003950 S5B-EH
N0802 00MYP06003950 S5B-EH
N0902 00MYP06003950 S5B-EH
N9002 00MYJ06006500 S10B-PH-K-S (LF)(SN)
N9003 00MYJ06006510 S11B-PH-K-S (LF)(SN)
N9004 00MYJ06006230 B3B-PH-K-S (LF)(SN)
N9006-9010 645010056069S 23P PLUG(C125Z1)
N9016 00MYJ06006480 S8B-PH-K-S (LF)(SN)
N9017 00MYJ06006520 S12B-PH-K-S (LF)(SN)
N9018-9021 645010056069S 23P PLUG(C125Z1)
N9022 00MYJ06006230 B3B-PH-K-S (LF)(SN)
N9030-9038 645010057062S 23P SOCKET(C125Z2)
N9041 61205049600AS 4P 80mm PH-SAN
N9046 61205049600AS 4P 80mm PH-SAN
N9051,9052 00MYJ06006440 S4B-PH-K-S (LF)(SN)
P0001 63101013000AS PWB P.AMP A350

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
