Denon AVR-4520 Service Manual

279
Ref. No. Part No. Part Name Remarks Q'ty New
C0399,0400 nsp CK73B1H102KT +1005
C0411-0413 nsp CK73B1A104KT +1005
C0414 nsp CK73B1H102KT +1005
C0415 nsp CK73B1A104KT +1005
C0416,0417 nsp CK73B1H102KT +1005
C0418 nsp CK73B1A104KT +1005
C0441-0443 nsp CK73B1A104KT +1005
C0445 nsp CK73B1H102KT +1005
C0446 nsp CK73B1A104KT +1005
C0447,0448 nsp CK73B1H102KT +1005
C0449 nsp CK73B1A104KT +1005
C0461-0463 nsp CK73B1A104KT +1005
C0464 nsp CK73B1H102KT +1005
C0465 nsp CK73B1A104KT +1005
C0466,0467 nsp CK73B1H102KT +1005
C0468 nsp CK73B1A104KT +1005
C0506 nsp CK73B1H102KT +1005
C0508,0509 nsp CC73CH1H120JT +1608
C0512-0515 nsp CK73B0J475KT +1608
C0516 nsp CK73B1A104KT +1005
C0517 nsp CK73B1H102KT +1005
C0518 nsp CK73B1A104KT +1005
C0519 nsp CK73B1H102KT +1005
C0520 nsp CK73B1A104KT +1005
C0521 nsp CK73B1H102KT +1005
C0522 nsp CK73B1A104KT +1005
C0523 nsp CK73B1H102KT +1005
C0524 nsp CK73B1A104KT +1005
C0525 nsp CK73B1H102KT +1005
C0526-0531 nsp CK73B1A104KT +1005
C0532-0535 nsp CK73B1H102KT +1005
C0536 nsp CK73B0J475KT +1608
C0539-0542 nsp CK73B0J475KT +1608
C0543 nsp CK73B1A104KT +1005
C0544 nsp CK73B1H102KT +1005
C0545 nsp CK73B1A104KT +1005
C0546 nsp CK73B1H102KT +1005
C0547-0554 nsp CK73B1A104KT +1005
C0555-0558 nsp CK73B1H102KT +1005
C0559 nsp CK73B0J475KT +1608
C0562 nsp CK73B0J475KT +1608
C0565,0566 nsp CK73B1A104KT +1005
C0567-0581 nsp
CK73B1H102KT +1005
C0603 nsp CK73B1E104KT +1608
C0604 00D2544645903 CE67C0J221MT(MVA) +REF
C0609 nsp CC73CH1H100DT +1608
C0610-0613 nsp CK73B1A104KT +1005
C0614 nsp CK73B1H102KT +1005
C0615 nsp CK73B1A104KT +1005
C0616 nsp CK73B1H102KT +1005
C0617-0620 nsp CK73B1A104KT +1005
C0621 nsp CK73B1H102KT +1005
C0622 nsp CK73B1A104KT +1005
C0625 nsp CK73B0J475KT +1608
C0626,0627 nsp CK73B1A104KT +1005
C0630-0632 nsp CK73B1A104KT +1005
C0633 nsp CC73CH1H150JT +1005
C0634 nsp CC73CH1H100DT +1005
C0635-0638 nsp CK73X5R0J106MT(2125)
C0640,0641 nsp CK73B1A104KT +1005
C0644,0645 nsp CK73B1E103KT(1005)
C0646 nsp CK73B1A104KT +1005
C0647 nsp CK73B1H102KT +1005
C0648,0649 nsp CK73X5R0J106MT(2125)
C0650 nsp CK73B1H102KT +1005
C0653,0654 nsp CK73B1H102KT +1005
C0659 nsp CK73B1A104KT +1005

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
