Denon AVR-4520 Service Manual

280
Ref. No. Part No. Part Name Remarks Q'ty New
C0661 nsp CK73B1A104KT +1005
C0664 nsp CK73B1A105KT +1608
C0665,0666 nsp CK73B1E104KT +1608
C0682-0689 nsp CK73B1H102KT +1608
C0701-0704 nsp CK73B1A104KT +1005
C0705-0714 nsp CC73CH1H391JT +1005
C0715-0722 nsp CK73B1A104KT +1005
C0723 00D2544645903 CE67C0J221MT(MVA) +REF
C0724,0725 nsp CK73B1A104KT +1005
C0726 nsp CC73CH1H101JT +1005
C0727 00D2544645903 CE67C0J221MT(MVA) +REF
C0728 nsp CC73CH1H7R0DT +1608
C0729 nsp CC73CH1H100DT +1608
C0730 nsp CC73CH1H101JT +1005
C0731 nsp CK73B1A104KT +1005
C0733-0736 nsp CK73B1A104KT +1005
C0737 nsp CK73B1E223KT +1608
C0738-0741 nsp CK73B1A104KT +1005
C0742,0743 nsp CC73CH1H101JT +1005
C0744 nsp CK73B1A104KT +1005
C0746 nsp CK73B1H102KT +1608
C0747 nsp CK73B1A104KT +1005
C0749,0750 nsp CC73CH1H150JT +1608
C0751 nsp CC73CH1H150JT +1005
C0752 nsp CK73X5R0J106MT(2125)
C0753 nsp CK73B0J475KT +1608
C0754 nsp CK73B1H102KT +1005
C0755 nsp CK73B0J475KT +1608
C0756 nsp CK73B1H102KT +1005
C0757 nsp CK73X5R0J106MT(2125)
C0758 nsp CK73B1A104KT +1005
C0759 nsp CK73B1E103KT(1005)
C0760 nsp CK73X5R0J106MT(2125)
C0764 nsp CK73B1A104KT +1005
C0766 nsp CC73CH1H471JT +1608
C0767 nsp CK73B1A105KT +1608
C0768 nsp CK73B1E103KT(1005)
C0769 nsp CK73B0J475KT +1608
C0775 nsp CK73B1H102KT +1608
C0800 nsp CK73B1A104KT +1005
C0802 nsp CK73B1E104KT +1608
C0803 00D2544645903 CE67C0J221MT(MVA) +REF
C0804 nsp
CK73B1A104KT +1005
C0806 nsp CC73CH1H220JT +1005
C0810 nsp CK73B1A104KT +1005
C0811 nsp CC73CH1H220JT +1005
C0815,0816 nsp CK73B1E103KT(1005)
C0819,0820 nsp CK73B1E103KT(1005)
C0823 nsp CK73B1A104KT +1005
C0826 nsp CK73B1E103KT(1005)
C0828 nsp CK73B1A104KT +1005
C0830 nsp CK73B1A104KT +1005
C0831 nsp CK73X5R0J106MT(2125)
C0832 nsp CK73B1A104KT +1005
C0833 nsp CK73X5R0J106MT(2125)
C0836 nsp CK73B1A104KT +1005
C0837 nsp CK73X5R0J106MT(2125)
C0838 nsp CK73B1A104KT +1005
C0839 nsp CK73X5R0J106MT(2125)
C0840 nsp CK73B1A104KT +1005
C0841 nsp CK73X5R0J106MT(2125)
C0842 00D2544645903 CE67C0J221MT(MVA) +REF
C0942 nsp CK73B1A104KT +1005
OTHERS PARTS GROUP
B0601 44431029600AD PWB BRACKET (USB)
K0800 64401015560AS HDMI CONNECTOR(A111989-W-15-T)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
