Denon AVR-4520 Service Manual

281
Ref. No. Part No. Part Name Remarks Q'ty New
L0003 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0007,0008 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0052,0053 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0501-0503 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0601 113410007504S DLW21SN181SQ2L
L0602,0603 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0605 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0607 00D2350130903 CHIP EMIFIL(11A121) +1608
L0608-0610 00D2470018905 RM73B--0R0KT +2125
L0611 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0613 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0701-0708 113410001506S DLW21SN900HQ2L
L0709-0711 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0712,0713 113410001506S DLW21SN900HQ2L
L0714 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0716-0718 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0800 113410007504S DLW21SN181SQ2L
L0801 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0806-0808 00D2350147909 E.FIL(BLM21PG221SN1)+2125
L0810-0812 00D2350147909 E.FIL(BLM21PG221SN1)+2125
N0051 64501008150AS 100P IMSA-9832S-100Y903
N0501 00D2051257978 7P FFC BASE (9610SD)
N0601 64401015000AS USB CONNECTOR(UAR80-4K5J00)
N0603 00MYJ0701855Y S5B-PH-SM4-TB (LF)(SN)
N0605 645010056090S 33P PLUG(C125Z1)
N0606 645010057062S 23P SOCKET(C125Z2)
N0607 645010057093S 33P SOCKET(C125Z2)
N0608 645010056090S 33P PLUG(C125Z1)
N0701 64401015110AS 1X4 RJ45 CONNECTOR(640-007BC)
N0702 645010057048S 19P SOCKET(C125Z2)
N0800 00D2051381103 USB CONNECTOR
N0801 00MYJ06006250 B5B-PH-K-S (LF)(SN)
N0802 00MYJ06006270 B7B-PH-K-S (LF)(SN)
N0803 00D2051313906 25P FFC.BASE(9610SCA +REF
X0101 14181006850AS TXC 7V(25MHZ)
X0201 14181006850AS TXC 7V(25MHZ)
X0301 14181006850AS TXC 7V(25MHZ)
X0503 14181006750AS TXC 7V(24MHZ)
X0701 14181006850AS TXC 7V(25MHZ)
Z3801 44431029700AD HDMI USB BRACKET
Z9999 44531014300AD SHIELD PLATE (DSP)

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
