Denon AVR-4520 Service Manual

97
Sound Mode
Surround Parameter
z1 During playback in PURE DIRECT mode, the surround
parameters are the same as in DIRECT mode.
z8 This setting is unavailable when the set sound mode
name contains “+PLg Music” or “+NEO:X Music”. For information on how to check the sound mode
z9 This setting is possible when the sound mode is
“Cinema” mode.
z10 This item can be selected when a Dolby TrueHD signal is
played.
z11 This item can be selected when a Dolby Digital or DTS
signal is played.
z12 This item can be selected when a Dolby Digital or DTS
signal or DVD-Audio is played.
z13 This setting is available when the set sound mode name
contains “+PLgz”. For information on how to check the sound mode.
Cinema EQ
Loudness
Management
z10
Dynamic
Compression
z11
Bass Sync
z12
Low Frequency
Effects
z12
Delay Time Effect Level Room Size
Height Gain
z13
Speaker Select
DIRECT/PURE DIRECT (2 channel)
z1
S S
DIRECT/PURE DIRECT (Multi-channel)
z1
S S S
DSD DIRECT (2 channel)
z1
DSD DIRECT (Multi-channel)
z1
S
EXTERNAL IN
S
STEREO
S S S S
MULTI CH IN
S
z8
S S
DOLBY PRO LOGIC gz S S S S
DOLBY PRO LOGIC gx S
z9
S S
DOLBY PRO LOGIC g S
z9
S S
DOLBY PRO LOGIC gx A-DSX S
z9
S S
DOLBY PRO LOGIC g A-DSX S
z9
S S
DTS NEO:X
S
z9
S S S
Audyssey DSX
®
S S S S S
DOLBY DIGITAL
S
z8
S S S S
DOLBY DIGITAL Plus
S
z8
S S S S
DOLBY TrueHD
S
z8
S S S S S
DTS SURROUND
S
z8
S S S S
DTS 96/24
S
z8
S S S
DTS-HD
S
z8
S S S
DTS Express
S
z8
S S S
MULTI CH STEREO
S S S S S
WIDE SCREEN
S S S S S S
SUPER STADIUM
S S S S S S S
ROCK ARENA
S S S S S S S
JAZZ CLUB
S S S S S S S
CLASSIC CONCERT
S S S S S S S
MONO MOVIE
S S S S S S S
VIDEO GAME
S S S S S S S
MATRIX
S S S S S S
VIRTUAL
S S S S

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
