Denon AVR-4520 Service Manual

98
Sound Mode
Surround Parameter
Tone
z14
Audyssey
Restorer
z18
z1 During playback in PURE DIRECT mode,
the surround parameters are the same as in DIRECT mode.
z14 This item cannot be set when “Dynamic EQ”
is set to “On”.
z15 In this sound mode, bass is +6 dB, and treble
is 0 dB (Default).
z16 In this sound mode, bass is +6 dB, and treble
is +4 dB (Default).
z17 This item cannot be set when “MultEQ
®
XT
32” is set to “Off” or “Graphic EQ”.
z18 This item can be set when the input signal is
analog, PCM 48 kHz or 44.1 kHz.
PRO LOGIC g/gx Music mode only
NEO:X mode
only
Panorama Dimension Center Width Center Gain MultEQ
®
XT 32
Dynamic EQ
z17
Dynamic
Volume
z17
Audyssey
LFC™
z17
Audyssey
DSX
®
DIRECT/PURE DIRECT (2 channel)
z1
DIRECT/PURE DIRECT (Multi-channel)
z1
DSD DIRECT (2 channel)
z1
DSD DIRECT (Multi-channel)
z1
EXTERNAL IN STEREO
S S S S S S
MULTI CH IN
S S S S S S
DOLBY PRO LOGIC gz S S S S S S S
DOLBY PRO LOGIC gx S S S S S S S S S S
DOLBY PRO LOGIC g S S S S S S S S S S
DOLBY PRO LOGIC gx A-DSX S S S S S S S S S S
DOLBY PRO LOGIC g A-DSX S S S S S S S S S S
DTS NEO:X
S S S S S S S
Audyssey DSX
®
S S S S S S S
DOLBY DIGITAL
S S S S S S
DOLBY DIGITAL Plus
S S S S S S
DOLBY TrueHD
S S S S S S
DTS SURROUND
S S S S S S
DTS 96/24
S S S S S S
DTS-HD
S S S S S S
DTS Express
S S S S S S
MULTI CH STEREO
S S S S S S
WIDE SCREEN
S S S S S S
SUPER STADIUM
S
z15
S S S S S
ROCK ARENA
S
z16
S S S S S
JAZZ CLUB
S S S S S S
CLASSIC CONCERT
S S S S S S
MONO MOVIE
S S S S S S
VIDEO GAME
S S S S S S
MATRIX
S S S S S S
VIRTUAL
S S S S S S

Denon AVR-4520 Specifications

General

Impedance	8 Ω
Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Power output per channel (1KHz@6 Ohm)	190 W
Power output per channel (20-20KHz@8 Ohm)	150 W
HDMI in	7
Composite video in	4
USB ports quantity	1
Digital audio optical in	2
Component video (YPbPr/YCbCr) in	3
Connectivity technology	Wired
Speakers connectivity type	-
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Ethernet LAN	Yes
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Silver
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS Neo:X, DTS-HD
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	780 W

Weight and Dimensions

Depth	423 mm
Width	434 mm
Height	195 mm
Weight	16500 g
