Denon AVR-E400 Service Manual

INPUT
7
INPUT PCB ASS'Y
NOTE:
X2000E3 : U.S.A. & Canada model X2000E2 : Europe model X2000E1C : China model X2000E1 : Asia model X2000K : Japan model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC4200 963239000650S R2A15218FP-U00R 8CH-VOL WITH 11 INPUT QFP100P J084152180010S 1
IC4206 00D2623727904 NJW1194V-TE1 2CH-ELECT VOL 4IN-1OUT, TONE SSOP32 X2000E1C,E2,E3,K J084119400010S 1
RESISTOR GROUP
R4205-4211 nsp 470-J,1/16W-1608REEL C20004716M160S 7
R4216-4221 nsp 820K-J,1/16W-1608REEL C20008246M160S 6
R4236 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4244,4245 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R4248 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4249-4252 nsp 470K-J,1/16W-1608REEL C20004746M160S 4
R4257 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4259-4262 nsp 100K-J,1/16W-1608REEL C20001046M160S 4
R4263-4270 nsp 10K-J,1/16W-1608REEL C20001036M160S 8
R4271-4277 nsp 100K-J,1/16W-1608REEL C20001046M160S 7
R4287 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
R4288-4290 nsp 0-J,1/16W-1608REEL C20000006M160S 3
R4292-4294 nsp 0-J,1/16W-1608REEL C20000006M160S 3
R4326 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4332 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4336 nsp 100K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001046M160S 1
R4341 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4344 nsp 100K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001046M160S 1
R4347 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R4348,4349 nsp 100K-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001046M160S 2
R4354 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4359 nsp 100-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001016M160S 1
R4360 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4363 nsp 0-J,1/16W-1608REEL X400E3 C20000006M160S 1
R4364 nsp 100-J,1/16W-1608REEL X2000E1C,E2,E3,K C20001016M160S 1
R4367 nsp 0-J,1/16W-1608REEL X400E3 C20000006M160S 1
R4370-4376 nsp 100-J,1/16W-1608REEL C20001016M160S 7
R4550 nsp 470-J,1/16W-1608REEL C20004716M160S 1
R4551,4552 nsp 820K-J,1/16W-1608REEL C20008246M160S 2
R4553 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4554 nsp 100K-J,1/16W-1608REEL C20001046M160S 1
CAPACIITORS GROUP
C4204 nsp COG330PF-J/50V-1608REEL D010331167160S 1
C4209-4211 nsp COG330PF-J/50V-1608REEL D010331167160S 3
C4225,4226 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C4229,4230 963134501890S 220UF-M/16V,8*11.5-5RE,SMS-SY D040221083090S 2
C4231 963134501900S 100UF-M/25V,6.3*11-5RE RA3-25V101MF3#8P-T2 D040101084210S 1
C4232-4236 963134502370S 47UF-M/16V,5*11-5RE.SMS SY D040470083080S 5 ＊
C4237-4239 963134502360S 47UF-M/63V,8*11.5-5RE,SMS-SY D040470088060S 3 ＊
C4240-4244 963134502370S 47UF-M/16V,5*11-5RE.SMS SY D040470083080S 5 ＊
C4245,4246 963134501890S 220UF-M/16V,8*11.5-5RE,SMS-SY D040221083090S 2
C4269 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4275 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D040100087070S 1
C4280 nsp X7R3300PF-K/50V-1608REEL X2000E1C,E2,E3,K D011332777160S 1
C4281 nsp 33UF-M/16V,5*11-5RE SMS SY X2000E1C,E2,E3,K D040330083050S 1
C4282 nsp X7R0.1UF-K/50V-1608REEL X2000E1C,E2,E3,K D011104577160S 1
C4283 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D040100087070S 1
C4284 00D9639006476 4.7UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D0404R7087250S 1
C4287 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D040100087070S 1
C4288 00D9639006476 4.7UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D0404R7087250S 1
C4290 nsp X7R0.1UF-K/50V-1608REEL X2000E1C,E2,E3,K D011104577160S 1
C4293 nsp 33UF-M/16V,5*11-5RE SMS SY X2000E1C,E2,E3,K D040330083050S 1
C4294 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D040100087070S 1
C4295 nsp X7R3300PF-K/50V-1608REEL X2000E1C,E2,E3,K D011332777160S 1
C4296 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C4304 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY X2000E1C,E2,E3,K D040100087070S 1
C4550-4553 nsp COG330PF-J/50V-1608REEL D010331167160S 4
C4554 nsp 0-J,1/16W-1608REEL C20000006M160S 1
OTHER PARTS GROUP
CN4006 nsp C125Z2-11 11P BtoB SOCKET(FEMALE) P=1.25MM L109012521120S 1
CN401 nsp 200MM/13P 20010HS-13=CKM2002HV-13 WH1007#26 L002201130010S 1
CN4700 nsp C125Z2-07 7P BtoB SOCKET(FEMALE) P=1.25MM X2000E3 L109012520720S 1
CN4703 nsp C125Z2-09 9P BtoB SOCKET(FEMALE) P=1.25MM L109012520920S 1
CP4200 nsp C125Z1-25 25P BtoB HEADER(MALE) P=1.25MM L109012512520S 1
CP4201 nsp C125Z1-31 31P BtoB HEADER(MALE) P=1.25MM L109012513120S 1
CP4203 nsp C125Z1-07 7P BtoB HEADER(MALE) P=1.25MM L109012510720S 1
CP4204 nsp C125Z1-17 17P BtoB HEADER(MALE) P=1.25MM L109012511720S 1
JACK4201,4202 00D9630132103 RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 2
The symbols in the column "Remarks" indicate the following destinations.
E400E3 : U.S.A. & Canada model

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
