7. RADIATOR ASSY
Proceeding : TOP COVER
RADIATOR ASSY
(1) Remove the screws.
(2) Cut the wire clamp band, then disconnect the connector wires and FFC.
View from the bottom
STYLE PIN : Loosen
cut
N2801
FFC
FFC
CP402 CP403 CP405
CP401
N3405
20
