2. Analog video
HDMI OUT output NG
Input CVBS
Function : CBL/SAT
To
A
Input COMPONENT
Function : CBL/SAT
Input
HDMI
To troubleshooting
3.2 HDMI/DVI.
Detail A Detail B
<HDMI B'D> UNIT test point
<VIDEO B'D> UNIT test point
B
C5003 + side
C5002 - side
J5010
J5033
J5035
CN5000 10pin
C5017 +side
C5018 +side
C5021 +side
R1309
R1306
R1307
R1308
CN3404-6pin
CN3404-5pin
CN3404-4pin
CN3404-3pin
