Denon AVR-E400 Service Manual

HDMI
20
REF No. Part No. Part Name Remarks Q'ty New Ver
C2486 963134000450S 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C2488 963134000450S 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C2491-2495 00D9630338606 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 5
C2496 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C2498 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C2499 00D9630325305 47UF-MVG/6.3V,4*3*5.1*5.3 REEL (Z8155) SY D050470081460S 1
C2601 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C2602,2603 nsp COG)12PF-G/50V-1005REEL GRM1555C1H120GA01D D010120157100S 2
C2605-2608 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 4
C2609-2619 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 11
C2620-2622 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 3
C2623 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2624 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2627-2630 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 4
C2631-2640 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 10
C2641-2643 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 3
C2645 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2648 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2653 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C2657 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2659 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2660-2667 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 8
C2676,2677 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 2
C2678 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2679,2680 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 2
C2801 nsp X7R0.022UF-K/25V-1608REEL D011223777160S 1
C2803 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C2806 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2807,2808 nsp COG)10PF-D/50V-1005REEL D011100117101S 2
C2811 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C2812 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2813 nsp X7R)470PF-K/50V-1005REEL D011471177101S 1
C2814 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C2815 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C2816 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C2817 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2818 nsp X7R1000PF-K/50V-1608REEL D011102777160S 1
C2819 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2821 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2823 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C2824,2825 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C2845 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C2846 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C2853 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3001 nsp X7R)1000PF-K/50V-1005REEL X2000E3 D011102177101S 1
C3002 nsp X7R)0.1UF-K/16V-1005REEL X2000E3 D011104177101S 1
C3003 nsp X7R)1000PF-K/50V-1005REEL X2000E3 D011102177101S 1
C3009 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3010 nsp X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C3011-3014 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 4
C3015 nsp COG)12PF-J/50V-1005REEL D011120167101S 1
C3016 nsp COG)15PF-J/50V-1005REEL D011150167101S 1
C3017-3019 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 3
C3021,3022 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C3202 nsp X7R)220PF-K/50V-1005REEL D011221177101S 1
C3205,3206 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 2
C3209 nsp X7R)0.1UF-K/16V-1005REEL E400E3,X2000E1C,E2,K D011104177101S 1
C3210 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3211 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 1
C3212 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3213-3216 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 4
C3414-3416 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 3
C3417 nsp COG)100PF-J/50V-1005REEL D011101167101S 1
C3418 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C3419-3424 nsp COG)100PF-J/50V-1005REEL D011101167101S 6
C3601-3605 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 5
C3619-3623 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 5
C3625-3629 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 5
C3631-3635 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 5
C3637-3641 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 5
C3643-3648 nsp X5R)10UF-K/16V-2012REEL GRM21BR61C106KE15L D011106573200S 6
C3649-3652 nsp COG15PF-J/50V-1608REEL D010150167160S 4
C3653 nsp COG)10PF-J/50V-1608REEL D010100167161S 1
C3667-3669 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 3
C3673-3676 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 4
C3677 nsp X7R)0.01UF-K/25V-1005REEL D011103174101S 1
C3678 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C3682 nsp X7R)1000PF-K/50V-1005REEL D011102177101S 1
C3695-3701 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 7
C3744 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C3752 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C3788 nsp X7R0.015UF-K/50V-1608REEL D011153777160S 1
C3789 00D9630325402 470UF-MVG/6.3V,8.3*9.0*10 REEL (Z8158) SY D050471081200S 1
C3790 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3792 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3795 nsp X7R)1UF-K/10V-1608REEL D011105772161S 1
C3797 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3799 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
C3802 963134501220S 470UF-M/6.3V,8*10 RVO-6V471MG10P2U-R2 ELNA D050471081330S 1
C3804 nsp X7R)0.1UF-K/16V-1005REEL D011104177101S 1
OTHER PARTS GROUP
K2201 963643003580S RCA-107C-02(OR) X2000E3 G600107C0020YS 1
K3001,3002 00D9630244703 EARPHONE JACK PJ-308-02 X2000E3 G40130802000YS 2
L1201-1203 nsp 0-J,1/10W-2012REEL C200000060200S 3
L1301-1313 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 13
L1602 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 1
L1605-1609 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 5
L1611-1615 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 5
L1617-1619 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 3
L1801 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 1
L2601-2603 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 3
L2801,2802 nsp DLW21SN900HQ2L COMMON MODE CHOKE COILS SMD2012 D311201219000S 2
L2804 nsp 0-J,1/10W-2012REEL C200000060200S 1
L2806 nsp DLW21SN181SQ2L COMMON MODE CHOKE COILS SMD2012 D311201211810S 1
L2807-2810 963115100320S CBW201209U221T 220ohm SMD2012 TYPE D340201202210S 4
L3401-3404 nsp 0-J,1/10W-2012REEL C200000060200S 4
L3601-3610 nsp 0-J,1/10W-2012REEL C200000060200S 10
L3613-3622 nsp 0-J,1/10W-2012REEL C200000060200S 10
L3625-3627 nsp BLM21PG221SN1 220ohm 2A SMD2012 TYPE D340201212210S 3

Denon AVR-E400 Specifications

General

HDMI Inputs	6
HDMI Outputs	1
3D Pass-through	Yes
4K Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Audyssey MultEQ	Yes
Network Connectivity	Yes
AirPlay	Yes
DLNA	Yes
Input Impedance	47 kOhms
Input Sensitivity	200 mV
Signal-To-Noise Ratio	100 dB
Response Bandwidth	10 Hz - 100 kHz
THD	0.08%
Tuner Presets	56
Tuner Bands	AM/FM
Frequency Response	10 Hz - 100 kHz
Video Upscaling	Yes
Bluetooth	No
Wi-Fi	No
Surround Sound Effects	DTS Neo:6
Audio D/A Converter	192kHz/24-bit
Inputs	HDMI, Digital Optical, Digital Coaxial, Analog
Outputs	HDMI, Headphones
