Denon AVR-E400

Input
CVBS
B
Check on set value of each IC.
Is they the following voltage
values?
HDMI B'D
CN3404-4pin : L(0V)
CN3404-5pin : H(5V)
Is the power supply voltage
correctly output?
V+5V : C5003 : + side
V-5V : C5002 : - side
Is the signal output from the
video amplier?
V : J5010
Check cable between main
unit and monitor or check
monitor.
Check cable between main unit and
player or check player.
Check power supply voltage
of IC5000 and IC5001, and
surrounding circuitry soldering.
Extend HDMI B'D using a jig.
HDMI B'D aw.
Check connection of FRONT
CONNECTOR BD and VIDEO BD.
NO
NO
NO
YES
YES
YES
b
Unless specied, VIDEO B'D part.
w
q
e
r
85
