Chapter 5 Installation and Wiring
93
(2) Installing the controller
The controller may be installed stand-alone or on the wall.
Install the controller as shown in the figure below.
Caution: Do not place anything within 200 mm from the air inlet and
air outlet on the controller.
Caution: <Wall-mounted installation>
The controller has not the air filter on the side of air outlet.
Therefore, install the controller as shown in the figure
below.
<Stand-alone Installation >
<Wall-mounted Installation >
Installation of SMT7
